1976 1979 850 T3 Civilian And LAPD Footrests Stand 850t3 Calif
| Position | Part Number | Description |
|---|---|---|
| 1 | 184203501 | RH craddle arm (#184203501) |
| 2 | 184221501 | LH craddle arm (#184221501) |
| 3 | 18423950 | RR BUMPER BRACE (#18423950) |
| 4 | 98623630 | SCREW (#98623630) |
| 5 | 18432050 | SIDE STAND LAPD (#18432050) |
| 6 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 7 | 14434000 | SPRING (#14434000) |
| 8 | 18443450 | FOOTREST (#18443450) |
| 9 | 18447050 | FLOORBOARD PAD EACH (#18447050) |
| 10 | 98107035 | BOLT CHROME (#98107035) |
| 11 | 92700073 | NUT (#92700073) |
| 12 | 12433000 | BUFFER-CENTER STAND STOP (#12433000) |
| 13 | 98054416 | BOLT (#98054416) |
| 14 | 98052440 | BOLT (#98052440) |
| 15 | 95021108 | WASHER (#95021108) |
| 16 | 13433440 | SUPPORT (#13433440) |
| 17 | 03432740 | STAND RETAINER (#03432740) |
| 18 | 92630110 | NUT (#92630110) |
| 19 | 14429500 | BOLT (ROD) (#14429500) |
| 20 | 98621697 | SCREW (#98621697) |
| 21 | 91181346 | SPACER (#91181346) |
| 22 | 98064345 | BOLT (#98064345) |
| 23 | 92603206 | NUT (#92603206) |
| 24 | 18486540 | LH BAG HOLDER (#18486540) |
| 25 | 18485040 | RH BAG HOLDER (#18485040) |
| 26 | 18487740 | SUPPORT (#18487740) |
| 27 | 18488740 | BRACKET (#18488740) |
| 28 | 98054325 | BOLT (#98054325) |
| 29 | 95000206 | WASHER (#95000206) |
| 30 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 32 | 93110060 | RUBBER WASHER (#93110060) |
| 33 | 95021106 | WASHER, WAVE (#95021106) |
| 34 | 92602206 | NUT (#92602206) USE STHN6MM |
| 35 | 98054322 | BOLT (#98054322) |
| 36 | 95100142 | WASHER (#95100142) |
| 37 | 93110067 | NYLON SPACER (#93110067) |
| 38 | 92630106 | NUT USE 92630707 (#92630106) |
