1976 1981 1000 Convert Rear Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 17630640 | REAR WHEEL (#17630640) |
| 2 | 17630740 | WHEEL RIM (#17630740) |
| 3 | 17631050 | SPOKE W/NIPPLE (#17631050) |
| 4 | 14611501 | SPOKE W/O NIPPLE (#14611501) |
| 5 | 92602316 | AXLE NUT (#92602316) |
| 6 | 14634400 | RING (#14634400) |
| 7 | ||
| 8 | 17633350 | AXLE (#17633350) |
| 9 | 92602208 | NUT (#92602208) |
| 10 | 14615902 | LOCKING TAB (#14615902) USE 14615901 |
| 11 | 98052445 | BOLT (#98052445) |
| 12 | ||
| 13 | 98054312 | BOLT (#98054312) |
| 14 | 95051106 | Tooth washer (#95051106) |
| 15 | 17335950 | LOCK PLATE (#17335950) |
| 16 | 14335303 | RING (#14335303) |
| 17 | 14335203 | HUB (#14335203) |
| 18 | 14336803 | CUSH DRIVE RUBBER (#14336803) |
| 19 | 17636050 | SPACER - METAL (#17636050) |
| 20 | 90272047 | CIRCLIP (#90272047) |
| 21 | 14620301 | FLANGE OR BEARING CARRIER (#14620301) |
| 22 | 92204220 | BEARING (#92204220) |
| 23 | ||
| 24 | 90706490 | O RING (#90706490) |
| 25 | 17633550 | CUP (#17633550) |
| 26 | 17633050 | WHEEL HUB COMPL (#17633050) |
| 27 | 12616101 | BALANCE WEIGHT (#12616101) |
| 27 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 27 | 12616103 | BALANCE WEIGHT (#12616103) |
| 27 | 17630240 | REAR WHEEL (#17630240) |
