1979 1983 Sp 1000 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 17490262 | FORK (#17490262) |
| 2 | 184940611 | Lower fork plate (#184940611) |
| 3 | 98072555 | BOLT BLACK (#98072555) |
| 4 | 91181016 | SPACER (#91181016) |
| 5 | 95007210 | WASHER (#95007210) |
| 6 | 17493160 | UPPER YOKE (#17493160) |
| 7 | 98612535 | SCREW BLACK (#98612535) |
| 8 | 18516660 | BUSHING (#18516660) |
| 9 | 95004208 | WASHER (#95004208) |
| 10 | 185226601 | LH sleeve (#185226601) |
| 11 | 185225601 | FORK SLEEVE (#185225601) |
| 12 | 96508021 | STUD BOLT (#96508021) |
| 13 | 98620312 | OIL DRAIN PLUG ALLEN BOLT (#98620312) |
| 14 | 95100116 | WASHER (#95100116) |
| 15 | 14525401 | FORK TUBE (#14525401) |
| 16 | 14504502 | PLUG (#14504502) |
| 17 | 90706238 | O RING (#90706238) |
| 18 | 90403449 | FORK SEAL (#90403449) |
| 19 | 14524500 | FORK DUST COVERS (#14524500) |
| 20 | 14526455 | DAMPER EA (#14526455) |
| 21 | 14527800 | TUBE (#14527800) |
| 22 | 14527900 | CUP (#14527900) |
| 23 | 17526960 | SPRING/YELLOW TAGGED SPRINGS ARE H/DUTY (#17526960) |
| 24 | 18526660 | SPRING (#18526660) |
| 25 | 18527960 | SPACER (#18527960) |
| 26 | 90271014 | RING USE 90271015 (#90271014) |
| 27 | 14527601 | SPRING RETAINER (#14527601) |
| 28 | 98622535 | SCREW (#98622535) |
| 29 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 30 | 98622422 | SCREW (#98622422) |
| 31 | 98620540 | SCREW (#98620540) |
| 32 | 92781100 | CAP NUT CHROME (#92781100) |
| 33 | 17496160 | HL BRACKET R/H (#17496160) |
| 34 | 17496260 | HL BRACKET LH (#17496260) |
| 35 | ||
| 36 | 18513460 | NUT (#18513460) |
| 37 | 18513560 | SHIM (#18513560) |
| 38 | 17517700 | DISC 1415 6600 (#17517700) |
| 39 | 14494600 | CUP (#14494600) |
| 40 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 41 | 14516700 | SHIM (#14516700) |
| 42 | 14517000 | RING DUST SEAL (#14517000) |
| 43 | 03530270 | STEERING DAMPER (#03530270) |
| 44 | 95100121 | WASHER (#95100121) |
| 45 | 98052325 | BOLT (#98052325) |
| 46 | 98054320 | BOLT (#98054320) |
| 47 | 95000206 | WASHER (#95000206) |
| 48 | 92630106 | NUT USE 92630707 (#92630106) |
| 49 | 17500200 | CLAMP (#17500200) |
| 50 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 51 | 17500760 | SPECIAL SCREW-DASH PANEL EXTENDER (#17500760) |
| 52 | 23999290 | DAMPER SET C (#23999290) |
| 53 | 17552361 | SPRING A (#17552361) |
| 55 | 95004215 | WASHER (#95004215) |
| 56 | 95100337 | WASHER (#95100337) |
| 57 | 92602210 | NUT (#92602210) |
| 58 | 18526560 | CAP (#18526560) |
| 59 | 98054420 | BOLT (#98054420) |
