1981 1984 Le Mans III 850 Battery
| Position | Part Number | Description |
|---|---|---|
| 1 | 17712400 | ALTERNATOR (#17712400) |
| 2 | 98620245 | SCREW (#98620245) |
| 3 | 95021105 | LOCK WASHER (#95021105) |
| 4 | ||
| 5 | 61712500 | CONNECTOR (#61712500) |
| 6 | ||
| 7 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 8 | ||
| 9 | 30717010 | SPARK PLUG BP6ES (#30717010) |
| 10 | 14716503 | Coil (#14716503) |
| 11 | 14747700 | CABLE (#14747700) |
| 12 | 98052345 | SCREW (#98052345) |
| 13 | 95100125 | WASHER (#95100125) |
| 14 | 91180718 | SPACER (#91180718) |
| 15 | 95000206 | WASHER (#95000206) |
| 16 | 92630106 | NUT USE 92630707 (#92630106) |
| 17 | 29703800 | REGULATOR (#29703800) USE 040003 |
| 18 | 98054320 | BOLT (#98054320) |
| 19 | 98054314 | SCREW (#98054314) |
| 20 | 95100141 | WASHER (#95100141) |
| 21 | 93110060 | RUBBER WASHER (#93110060) |
| 22 | 31735360 | IGN SWITCH (#31735360) |
| 23 | 14712459 | SCREW ALTERNATOR BOLT (BOSCH) (#14712459) |
| 24 | 61712600 | CONNECTOR (#61712600) |
| 25 | 19707100 | CAP (#19707100) |
| 26 | 19733350 | COVER, SOLENOID NLA 7/15/02 (#19733350) |
| 27 | 14736856 | LOCK W/ KEY (#14736856) |
| 28 | ||
| 29 | 14704205 | Cover (#14704205) |
| 30 | 98202516 | SCREWS (#98202516) |
| 31 | 95100059 | WASHER (#95100059) |
| 32 | 95000205 | WASHER (#95000205) |
| 33 | 92602205 | NUT (#92602205) |
| 34 | 17748500 | CABLE (#17748500) |
| 35 | 28704552 | BATTERY (#28704552) |
| 36 | ||
| 37 | 28704850 | STRAP (#28704850) |
| 38 | 14705500 | BATTERY STRAP, REAR (#14705500) |
| 39 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 40 | 14748450 | BATTERY GROUND STRAP (#14748450) |
| 41 | 25706700 | DUST COVER (#25706700) |
| 42 | 19732500 | HORN, HL OR STARTER RELAY (#19732500) |
| 43 | 98054210 | BOLT (#98054210) |
| 44 | 30730711 | VALEO STARTER (#30730711) |
| 45 | 14730558 | SOLENOID SEE 1473 0558A (#14730558) |
| 46 | 14730570 | REV.KIT (#14730570) |
| 47 | 98052480 | SCREW (#98052480) |
| 48 | 28135650 | STARTER DEVICE BRACKET (#28135650) |
| 49 | 95004208 | WASHER (#95004208) |
| 50 | 92602208 | NUT (#92602208) |
| 51 | ||
| 52 | 14716400 | DISTRIBUTOR BASE GASKET (#14716400) |
| 53 | 14716200 | GEAR (#14716200) |
| 54 | 95510318 | PIN (#95510318) |
| 55 | 14715700 | PLATE (#14715700) |
| 56 | 98052430 | BOLT (#98052430) |
| 57 | 14615901 | WASHER (#14615901) |
| 58 | 91180907 | SPACER (#91180907) |
| 59 | ||
| 60 | 14719800 | POINTS & COND. DISTRIBUTOR KIT (#14719800) |
| 61 | 28929940 | TOOL KIT 14929955 (#28929940) |
| 62 | 28900050 | #62 Operator's handbook (#28900050) |
| 62 | 28900051 | O MANL 850 L/M 850 III (#28900051) |
| 62 | 28900052 | Le Mans III Owners Manual (# 2890 0052) USE 28900051 (#28900052) |
| 62 | 28900053 | #62 Operator's handbook (#28900053) |
| 63 | 19741336 | 19741335 (#19741336) |
