1981 1984 Le Mans III 850 Handlebar Controls
| Position | Part Number | Description |
|---|---|---|
| 1 | 14600755 | HANDLEBAR 850 LM II,LM III, CX100 LM HALF (#14600755) |
| 2 | 14600655 | HANDLEBAR 850 LM II/LM III HALF H.BAR (#14600655) |
| 3 | 28764050 | PLATE (#28764050) |
| 4 | 98052470 | BOLT (#98052470) |
| 5 | 95000208 | WASHER (#95000208) |
| 6 | 27761560 | SPEEDOMETER KPH (#27761560) |
| 7 | 28769550 | BADGE (#28769550) |
| 8 | 28760450 | CABLE 1094900 INNER (#28760450) |
| 9 | 28767250 | TACH (#28767250) |
| 10 | 14769200 | TACH DRIVE (#14769200) |
| 11 | 28768150 | TACH CABLE 25 (#28768150) |
| 12 | 17762200 | RUBBER BOOT (#17762200) |
| 13 | 17784960 | VOLTMETER (#17784960) |
| 14 | 28766950 | INST PANEL (#28766950) |
| 15 | 17765560 | SPACER (#17765560) |
| 16 | 17783960 | SPACER (#17783960) |
| 17 | 95100060 | WASHER (#95100060) |
| 18 | 28766250 | DASH COVER (#28766250) |
| 19 | 28765250 | INST HOLDER (#28765250) |
| 20 | 19768580 | #19 Lampholder (#19768580) |
| 21 | 19768680 | BULB HOLDER (#19768680) |
| 22 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 23 | 17738061 | SWITCH HORN/T/SIG (#17738061) |
| 24 | 14603455 | USE TOMMASELLI 14603550 (#14603455) |
| 25 | 14603500 | RH GRIP (#14603500) |
| 26 | 14603000 | GRIP (#14603000) USE1137800 |
| 27 | 19605501 | LEVER W/BRACKET-CLUTCH BLACK (#19605501) |
| 29 | 98622318 | SCREW (#98622318) |
| 30 | 18745701 | SWITCH (#18745701) |
| 31 | 98270621 | SCREW (#98270621) |
| 32 | ||
| 33 | 12763300 | SPEEDOMETER DRIVE GEAR (#12763300) |
| 34 | ||
| 35 | 92630105 | NUT (#92630105) |
| 36 | 49609601 | TIE STRAP (#49609601) |
| 37 | 14768650 | BULB SOCKET A (#14768650) |
| 38 | 93450120 | BULB ALL GLASS (#93450120) |
| 39 | 98620335 | SCREWS (#98620335) |
| 40 | 95001205 | WASHER (#95001205) |
| 41 | 92630106 | NUT USE 92630707 (#92630106) |
| 42 | 91180809 | SPACER (#91180809) |
| 43 | 14748155 | CABLE ASSY. (#14748155) |
| 46 | 35755780 | RUBBER BOOT (#35755780) |
| 47 | 61740551 | CONNECTOR (#61740551) |
| 48 | 17756060 | CAP (#17756060) |
| 49 | 17756160 | CONNECTION (#17756160) |
| 50 | 14749755 | PLATE (#14749755) |
| 51 | 92781081 | CAP NUT (#92781081) USE STCN8MM |
| 52 | 65604400 | BLOCK (#65604400) |
| 53 | 28769850 | LH MIRROR (#28769850) |
| 54 | 28769450 | RH MIRROR (#28769450) |
