1982 1986 V 35 C V 50 C 350 Exhaust Intake Unit
| Position | Part Number | Description |
|---|---|---|
| 1 | 19112680 | CARB PHBH28BD (#19112680) |
| 2 | 19112681 | CARB PHBH28BS (#19112681) |
| 3 | 19114320 | #10 Hose (#19114320) |
| 3 | 19114360 | INTAKE SLEEVE USE 31114383 (#19114360) |
| 4 | 93305032 | CLAMP (#93305032) |
| 5 | 19114400 | AIR INTAKE (#19114400) |
| 5 | 19114480 | AIR INTAKE (#19114480) |
| 6 | 19114680 | RING (#19114680) |
| 6 | 90706315 | O RING (#90706315) |
| 7 | 98054214 | BOLT (#98054214) |
| 8 | 95000205 | WASHER (#95000205) |
| 9 | 19114300 | INDUCTION MANIFOLD (AIR BOX) (#19114300) |
| 10 | 93305092 | CLAMP (#93305092) |
| 11 | 17114650 | ELBOW (#17114650) |
| 12 | 00823942090 | Breather pipe (#00823942090) |
| 13 | 90706552 | O RING (#90706552) |
| 15 | 19156701 | BREATHER ELEMEN (#19156701) |
| 16 | 19156900 | REAR BREATHER (#19156900) |
| 17 | 19156001 | #11 Breather pipe (#19156001) |
| 18 | 17113450 | CARB CLAMP (#17113450) |
| 19 | 17113651 | AIR FILTER (#17113651) |
| 20 | 17114050 | Air Filter Chamber (17114050) (#17114050) |
| 21 | 19114100 | PLATE (#19114100) |
| 22 | 95129100 | WASHER (#95129100) |
| 23 | 92670305 | WING NUT (#92670305) |
| 24 | 98052222 | BOLT (#98052222) |
| 25 | 95100059 | WASHER (#95100059) |
| 26 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 27 | 92630105 | NUT (#92630105) |
| 29 | 61108400 | CLAMP (#61108400) |
| 30 | 61108500 | CLIP (#61108500) |
| 31 | 23133100 | CHOKE LEVER ASSEMBLY WAS 27133160 (#23133100) |
| 32 | 19133500 | CABLE (#19133500) |
| 33 | 19134000 | CABLE (#19134000) |
| 34 | 19120735 | RH EXHAUST PIPE MONZA (#19120735) |
| 35 | 19120736 | LH EXHAUST PIPE MONZA (#19120736) |
| 36 | 19025280 | GASKET, EXHAUST (#19025280) |
| 36 | 61025200 | Exhaust pipe gasket (#61025200) |
| 37 | 61025400 | SPACER EACH 1/2 (#61025400) |
| 38 | 19121050 | HEADER PIPE FLANGE (#19121050) |
| 39 | 61013800 | SPRING WASHER (#61013800) |
| 40 | 92701062 | NUT (#92701062) |
| 41 | 19122936 | MUFFLER V65C, V50 SERIES LH (#19122936) |
| 42 | 19123036 | MUFFLER RH V65C (#19123036) |
| 43 | 61126920 | CLAMP (#61126920) |
| 44 | 19121135 | PIPE (#19121135) |
| 44 | 23121180 | CONN PIPE (#23121180) |
| 45 | 19113900 | GASKET (#19113900) |
| 46 | 19123435 | CLAMP (#19123435) |
| 47 | 61127520 | A/M BOLT (#61127520) |
| 48 | 92602208 | NUT (#92602208) |
| 49 | 61270300 | WASHER (#61270300) |
| 50 | 19128660 | PLATE (#19128660) |
| 51 | 35108450 | HOSE CLIP (#35108450) |
| 52 | 19128760 | PLATE (#19128760) |
| 53 | 98054535 | BOLT (#98054535) |
| 54 | 95021110 | WASHER (#95021110) |
| 55 | 92602410 | NUT (#92602410) |
| 56 | 61127220 | Ring Nut (#61127220) |
