1983 1986 California II 1000 Carburetors
| Position | Part Number | Description |
|---|---|---|
| 22 | 17939950 | CARB.GSKT. KIT VHB 24, 29 & 30 CARBS SQUARE SLIDE (#17939950) |
| 24 | 12937200 | CABLE ADJUSTER (#12937200) |
| 25 | 12937300 | NUT (#12937300) |
| 26 | 13937900 | SCREW (#13937900) |
| 27 | ||
| 29 | 13937600 | SPRING (#13937600) |
| 30 | 13937800 | VALVE CHOKE (#13937800) |
| 31 | 13936200 | SCREW (#13936200) |
| 32 | 13936300 | SPRING (#13936300) |
| 33 | 13936600 | SCREW (#13936600) |
| 34 | 13936700 | SPRING (#13936700) |
| 35 | 13932800 | SCREW NLA (#13932800) |
| 36 | 13932900 | WASHER (#13932900) |
| 37 | 13935000 | COVER (#13935000) |
| 39 | 13937100 | SPRING (#13937100) |
| 40 | 55938585 | NEEDLE CLIP (#55938585) |
| 41 | 28937511 | SLIDE 50/3 A (#28937511) |
| 42 | 28937711 | SLIDE NEEDLE K23 (#28937711) |
| 43 | 14936800 | NUT (#14936800) |
| 44 | 14938700 | RING (#14938700) |
| 45 | 14938900 | INSUL. BUSHING USE 17938960 (#14938900) |
| 46 | 14938600 | SCREW (#14938600) |
| 47 | ||
| 48 | 17939000 | PUMP PLUNGER (#17939000) |
| 51 | 17939300 | SPRING (#17939300) |
| 52 | 17939400 | JET HOLDER (#17939400) |
| 53 | 18935750 | JET (#18935750) USE 1486125 |
| 55 | 13933700 | CARB BOWL NUT (#13933700) |
| 56 | 17936067 | STARTER JET #75 (#17936067) |
| 58 | 28935511 | ATOMIZER #AB264 (#28935511) |
| 59 | 10935900 | JET (#10935900) #50. USE 148650 |
| 60 | 13934800 | FLOAT NEEDLE VALVE (#13934800) |
| 61 | 13934600 | CARB.ADAPTER BLACK PLASTIC (#13934600) |
| 62 | 43934000 | Fuel Filter Screen (43934000) (#43934000) |
| 63 | 10934900 | BOLT (#10934900) |
| 65 | 14933000 | FLOATS - ALL BIG BLOCK (#14933000) |
| 66 | 13933100 | FLOAT PIN (13933100) (#13933100) |
| 68 | 13934400 | BODY (#13934400) |
| 69 | 14938800 | JET HOLDER KIT (#14938800) |
