1983 1986 California II 1000 Cases Windscreen Kit
| Position | Part Number | Description |
|---|---|---|
| 1 | 29577200 | WINDSHIELD California 2 (#29577200) |
| 2 | 29506800 | RH BRACKET (#29506800) |
| 3 | 29506900 | LH BRACKET (#29506900) |
| 4 | 29999260 | SADDLEBAG SET C (#29999260) |
| 6 | 29485000 | RH BAG BAR (#29485000) |
| 7 | 29486500 | LH BAG BAR (#29486500) |
| 8 | 29458201 | R REAR CRASHBAR A (#29458201) |
| 9 | 29458801 | CRASH BAR ENGINE GUARD (#29458801) |
| 10 | 29486100 | SCREW (#29486100) |
| 11 | 98822420 | SCREW (#98822420) |
| 12 | 95021108 | WASHER (#95021108) |
| 13 | 92602208 | NUT (#92602208) |
| 14 | 18578451 | BRACKET (#18578451) |
| 15 | 98074425 | BOLT BLACK (#98074425) |
| 17 | 92601208 | NUT (#92601208) |
| 18 | 98074416 | BOLT (#98074416) |
| 19 | 95001208 | WASHER (#95001208) |
| 20 | 29484000 | LOCK (#29484000) |
| 21 | 29466520 | PARCEL GRIP (#29466520) |
| 22 | 29467320 | LUGGAGE RACK SUPPORT (#29467320) |
| 23 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 24 | 95004206 | WASHER (#95004206) |
| 25 | 92781081 | CAP NUT (#92781081) USE STCN8MM |
| 26 | 29487620 | REAR TRUNK CA2 (#29487620) |
| 27 | 29482000 | BADGE NLA (#29482000) |
| 28 | 29753821 | REAR TRUNK LOCK (#29753821) |
| 29 | 29753822 | BAG SUPPORT (#29753822) |
| 30 | ||
| 31 | 98052335 | BOLT (#98052335) |
| 32 | 92602206 | NUT (#92602206) USE STHN6MM |
| 33 | 95000206 | WASHER (#95000206) |
