1983 1986 California II 1000 Front Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 29490200 | FORK (#29490200) |
| 2 | 28494033 | LWR FORK YOKE 63494021 (#28494033) |
| 3 | 95004210 | WASHER (#95004210) |
| 3 | 98620560 | SCREW (#98620560) |
| 4 | 91181110 | BUSHING (#91181110) |
| 6 | 17493160 | UPPER YOKE (#17493160) |
| 7 | 98620540 | SCREW (#98620540) |
| 8 | 18516660 | BUSHING (#18516660) |
| 9 | 63492700 | **NLA** 3/01 SEAL (#63492700) |
| 10 | 17522620 | FORK LEG LH (#17522620) |
| 11 | 17522520 | FORK LEG RH (#17522520) |
| 12 | ||
| 13 | 98622312 | SCREW (#98622312) |
| 14 | 95100116 | WASHER (#95100116) |
| 15 | 63525400 | FORK TUBE (#63525400) |
| 16 | 14936400 | NUT (#14936400) |
| 17 | 90706238 | O RING (#90706238) |
| 18 | 90403449 | FORK SEAL (#90403449) |
| 19 | 14524500 | FORK DUST COVERS (#14524500) |
| 20 | 29526400 | FRONT SHOCK (#29526400) |
| 21 | 14527800 | TUBE (#14527800) |
| 22 | 14527900 | CUP (#14527900) |
| 23 | 18526960 | SPRING (#18526960) |
| 24 | 18526660 | SPRING (#18526660) |
| 25 | 18527960 | SPACER (#18527960) |
| 26 | 90271014 | RING USE 90271015 (#90271014) |
| 27 | 29527400 | SPACER (#29527400) |
| 28 | 98620590 | SCREW (#98620590) |
| 29 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 31 | 92602210 | NUT (#92602210) |
| 32 | 63496120 | TUBE RIGHT (#63496120) |
| 33 | 63496220 | TUBE LEFT (#63496220) |
| 34 | 18513460 | NUT (#18513460) |
| 35 | 18513560 | SHIM (#18513560) |
| 36 | 14494600 | CUP (#14494600) |
| 37 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 38 | 14516700 | SHIM (#14516700) |
| 39 | 14517000 | RING DUST SEAL (#14517000) |
| 40 | 62497820 | COVER ACROSS FRONT FORKS (#62497820) |
| 41 | 98326016 | SCREW, PAN HEAD (#98326016) |
| 42 | 29578800 | BRACKET (#29578800) |
| 43 | 95001206 | WASHER (#95001206) |
| 44 | 98054320 | BOLT (#98054320) |
| 45 | 92602308 | NUT (#92602308) |
| 46 | 98074416 | BOLT (#98074416) |
| 47 | 98054420 | BOLT (#98054420) |
| 48 | 29550201 | CAL II RR SHOCK (#29550201) |
| 49 | 29552300 | SPRING REAR (#29552300) |
| 50 | 95100256 | WASHER (#95100256) |
| 51 | 18526560 | CAP (#18526560) |
| 52 | 28556150 | PIPE (#28556150) |
| 53 | 28556250 | VALVE (#28556250) |
| 54 | 28556350 | WASHER SPECIAL PLASTIC WASHER (#28556350) |
| 55 | 28556450 | SCREW (#28556450) |
| 58 | 19529660 | TUBE (#19529660) |
| 59 | 17500200 | CLAMP (#17500200) |
| 60 | 96508066 | SHORT STUD (#96508066) |
| 61 | 96508045 | SCREW (#96508045) |
| 62 | 95021108 | WASHER (#95021108) |
| 63 | 92602208 | NUT (#92602208) |
| 64 | 19923480 | M. G. EMBLEM (#19923480) |
| 65 | 39922200 | PLATE (#39922200) |
| 66 | 91181405 | SPACER (#91181405) |
| 67 | 14551655 | BUSHING (#14551655) |
| 68 | 92630108 | NUT 8MM (#92630108) |
