1983 1986 California II 1000 Rh Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 28660178 | MASTER CYL ASSY B (#28660178) |
| 2 | 17605652 | BRAKE LEVER (#17605652) |
| 3 | 17659450 | SCREW KIT (#17659450) |
| 4 | 95990034 | BANJO BOLT (#95990034) |
| 5 | 98622530 | BOLT (#98622530) |
| 6 | 14659000 | CALIPER KIT (#14659000) |
| 7 | 39663801 | DUST CAP (#39663801) |
| 8 | 18657140 | HOSE UPPER REAR (#18657140) |
| 9 | 95990028 | SCREW (#95990028) |
| 10 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 11 | 14656800 | BLOCK (#14656800) |
| 12 | 98054320 | BOLT (#98054320) |
| 13 | 95004205 | WASHER (#95004205) |
| 14 | 25657001 | BRAKE LIGHT SWITCH (#25657001) |
| 15 | 17661152 | MASTER CYL. COVER (#17661152) |
| 16 | 17658460 | CLAMP (#17658460) |
| 17 | 17658260 | RUBBER RING (#17658260) |
| 18 | 17661052 | MASTER CYLINDER LID W/ BELLOWS (#17661052) |
| 19 | 17659352 | Front Master Cylinder Kit (#17659352) |
| 19 | 92602210 | NUT (#92602210) |
| 20 | 14659200 | BLEEDER SCREW KIT (1 PR) (#14659200) |
| 21 | 14659100 | BRAKE PINS KIT 2 PER BAG (#14659100) |
| 22 | 28652301 | CALIPER RH (#28652301) |
| 23 | 17654760 | COVER (#17654760) |
| 24 | 28654601 | (#28654601) |
| 25 | 98620540 | SCREW (#98620540) |
| 26 | 95004210 | WASHER (#95004210) |
| 27 | 95100332 | SHIM 0.5 MM (#95100332) |
| 27 | 95100333 | SHIM 0.8 MM (#95100333) |
| 28 | 95129180 | WAVE WASHER (#95129180) |
