1983 1986 California II 1000 Tank Seats From Frml vt175000
| Position | Part Number | Description |
|---|---|---|
| 1 | 29100201 | TANK - BLACK (#29100201) |
| 1 | ||
| 1 | 29100203 | FUEL-TANK -WHITE 29100203 (#29100203) |
| 2 | 18104000 | GAS CAP COVER (#18104000) |
| 2 | 29104001 | TANK COVER - BLACK (#29104001) |
| 2 | 29104003 | COVER WHITE (#29104003) |
| 3 | 14736856 | LOCK W/ KEY (#14736856) |
| 4 | 18105001 | LATCH (#18105001) |
| 5 | 19104950 | RETAINER (#19104950) |
| 6 | 14917300 | BADGE (#14917300) |
| 7 | 14105100 | HOLDER OR CLIP (#14105100) |
| 8 | 17105460 | PETCOCK (#17105460) |
| 9 | 17105461 | PETCOCK RH (#17105461) |
| 10 | 90714103 | GASKET FUEL TAP TO GAS TANK (#90714103) |
| 11 | 29476201 | RH COVER--BLACK (#29476201) |
| 11 | 29476202 | RH COVER--RED (#29476202) |
| 11 | 29476203 | RH COVER-WHITE (#29476203) |
| 12 | 29476301 | LH COVER--Blank (#29476301) |
| 12 | 29476302 | LH COVER--RED (#29476302) |
| 12 | 29476303 | COVER WHITE LH (#29476303) |
| 13 | 29460501 | #13 Saddle (#29460501) |
| 13 | 29460520 | SEAT W/HANDGRIP CA II LONG (#29460520) |
| 14 | 29466500 | CARRIER (#29466500) |
| 15 | 29923300 | TRANSFER SET (#29923300) |
| 16 | ||
| 17 | 14102600 | STRAP (#14102600) |
| 18 | 98054210 | BOLT (#98054210) |
| 19 | 95129100 | WASHER (#95129100) |
| 20 | 28103946 | GAS TANK CAP (#28103946) |
| 21 | 141022551 | PLATE (#141022551) |
| 22 | 93180706 | PLUG (#93180706) |
| 23 | 17101242 | PLATE RED MADER (#17101242) |
| 23 | 29101200 | BRACKET - BLACK (#29101200) |
| 23 | 29101201 | BRACKET - WHITE(#29101201) |
| 24 | 98202510 | SCREW (#98202510) |
| 26 | 29464300 | EARLY H/GRIP (#29464300) |
| 26 | 29464320 | HANDGRIP (#29464320) |
| 27 | 98052490 | BOLT (#98052490) |
| 28 | 95021108 | WASHER (#95021108) |
| 29 | 92602208 | NUT (#92602208) |
| 30 | 98054422 | BOLT (#98054422) |
| 31 | 61270300 | WASHER (#61270300) |
| 32 | 92630108 | NUT 8MM (#92630108) |
| 33 | 14575970 | RUBBER CAP A (#14575970) |
| 34 | 29462920 | SUPPORT PIN (#29462920) |
| 35 | 92602210 | NUT (#92602210) |
| 36 | 27468720 | LOCK (#27468720) |
| 37 | 98054216 | SCREW (#98054216) |
| 38 | 95000205 | WASHER (#95000205) |
| 39 | 92630105 | NUT (#92630105) |
