1983 1988 Sp II 1000 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 28494010 | STEERING BASE (#28494010) |
| 2 | 98072555 | BOLT BLACK (#98072555) |
| 3 | 95007210 | WASHER (#95007210) |
| 4 | 91181016 | SPACER (#91181016) |
| 5 | 28493100 | STEERING HEAD (#28493100) |
| 6 | 98610540 | BOLT (#98610540) |
| 7 | 98612535 | SCREW BLACK (#98612535) |
| 8 | 18516660 | BUSHING (#18516660) |
| 9 | 285225401 | #09 RH sleeve (#285225401) |
| 10 | 285226401 | #10 LH sleeve (#285226401) |
| 11 | 98622318 | SCREW (#98622318) |
| 12 | 95100116 | WASHER (#95100116) |
| 13 | 28525440 | FORK TUBE A (#28525440) |
| 14 | 90403857 | FORK SEAL (#90403857) USE 429013 |
| 15 | 28524500 | DUST CAP NLA (#28524500) |
| 17 | 28528250 | FRONT AIR VALVE (#28528250) |
| 18 | 28556350 | WASHER SPECIAL PLASTIC WASHER (#28556350) |
| 19 | 28529650 | TUBE (#28529650) |
| 20 | 28526540 | WASHER (#28526540) |
| 21 | 90706282 | O RING (#90706282) |
| 24 | 28526940 | FORK SPRING A (#28526940) |
| 25 | 28527940 | FORK SPRING SPACER (#28527940) |
| 26 | 28526640 | LOWER SPRING A (#28526640) |
| 31 | 98622530 | BOLT (#98622530) |
| 32 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 33 | 98820540 | BOLT (#98820540) |
| 34 | 92781100 | CAP NUT CHROME (#92781100) |
| 35 | 28496140 | RH STAY TUBE A (#28496140) |
| 36 | 28496240 | LH H/L MOUNT (#28496240) |
| 37 | 28492700 | SEAL (#28492700) |
| 38 | 18513460 | NUT (#18513460) |
| 39 | 18513560 | SHIM (#18513560) |
| 40 | 92630106 | NUT USE 92630707 (#92630106) |
| 41 | 17500200 | CLAMP (#17500200) |
| 42 | 96508045 | SCREW (#96508045) |
| 44 | 92602208 | NUT (#92602208) |
| 45 | 98052490 | BOLT (#98052490) |
| 46 | 95004208 | WASHER (#95004208) |
| 48 | 28527540 | LOWER SHOCK BUSHING (#28527540) |
| 49 | 20527620 | #14 Bush (#20527620) |
| 50 | 91180812 | Spacer (#91180812) |
