1983 1988 Sp II 1000 Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 2 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 3 | 14494600 | CUP (#14494600) |
| 4 | 14516700 | SHIM (#14516700) |
| 5 | 14517000 | RING DUST SEAL (#14517000) |
| 7 | 28556150 | PIPE (#28556150) |
| 8 | 28556250 | VALVE (#28556250) |
| 9 | 28556450 | SCREW (#28556450) |
| 10 | 28556350 | WASHER SPECIAL PLASTIC WASHER (#28556350) |
| 11 | 95100256 | WASHER (#95100256) |
| 12 | 98074416 | BOLT (#98074416) |
| 13 | 95000208 | WASHER (#95000208) |
| 14 | 98822425 | SCREW (#98822425) |
| 15 | 14551655 | BUSHING (#14551655) |
| 16 | 93180206 | RUBBER PLUG (#93180206) |
| 17 | 17530260 | STEERING DAMPER (#17530260) |
| 19 | 98052325 | BOLT (#98052325) |
| 20 | 98054320 | BOLT (#98054320) |
| 21 | 95000206 | WASHER (#95000206) |
| 22 | 92630106 | NUT USE 92630707 (#92630106) |
| 23 | 285289501 | plate (#285289501) |
| 24 | 95021106 | WASHER, WAVE (#95021106) |
| 25 | 98054314 | SCREW (#98054314) |
