1983 1994 Le Mans 1000 Fairing 1985 1986
| Position | Part Number | Description |
|---|---|---|
| 1 | 28575361 | COWLING-COMPLETE-RED USE 28755461 BARE OR (#28575361) |
| 1 | 28575362 | FAIRING-WHITE C (#28575362) |
| 2 | 28575460 | LEMANS 4 FAIRING BARE - NO LONGER AVAILABLE 97 inch (#28575460) |
| 2 | 285754601 | #02 Naked fairing (#285754601) |
| 2 | 28575462 | BARE COWL-WHITE C (#28575462) |
| 2 | 28575470 | USE 28575460 (#28575470) |
| 3 | 28577260 | LM 1000 W/SHLD (#28577260) |
| 4 | 98280412 | SCREW (#98280412) |
| 5 | 95007204 | WASHER (#95007204) |
| 6 | 92781040 | NUT (#92781040) |
| 7 | 92601004 | NUT (#92601004) |
| 8 | 28571760 | COVER (#28571760) |
| 9 | 98326016 | SCREW, PAN HEAD (#98326016) |
| 10 | 28578660 | UPPER BRACKET A (#28578660) |
| 11 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 12 | 91180607 | SPACER (#91180607) |
| 13 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 14 | 95000206 | WASHER (#95000206) |
| 15 | 95021106 | WASHER, WAVE (#95021106) |
| 16 | 92602206 | NUT (#92602206) USE STHN6MM |
| 17 | 28578810 | BRACKET (#28578810) |
| 18 | 98054312 | BOLT (#98054312) |
| 21 | 90706035 | GROMMET (#90706035) |
| 22 | 285703501 | #22 RH side panel (#285703501) |
| 22 | 28570351 | RH SIDE--RED USE 2857 0370 (#28570351) |
| 22 | 28570353 | SIDE--WHITE (#28570353) |
| 22 | 28570370 | RH LWR SIDE-RED B (#28570370) |
| 23 | 285704501 | LH side panel (#28570450) (#285704501) |
| 23 | 28570451 | SIDE RED USE 2857 0470 (#28570451) |
| 23 | 28570453 | SIDE (#28570453) |
| 23 | 28570470 | LH LWR.SIDE-RED (#28570470) |
| 24 | 28570850 | TRAVERSE MEMBER (#28570850) |
| 25 | 17570561 | BRACKET (#17570561) |
| 26 | 98074420 | BOLT BLACK (#98074420) |
| 27 | ||
| 28 | 17451750 | PLATE (#17451750) |
| 29 | 14609650 | TIE WRAP (#14609650) |
