1983 1994 Le Mans 1000 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 28400160 | FRAME ASSY C (#28400160) |
| 1 | 28400178 | FRAME-BLACK C (#28400178) |
| 1 | 28400179 | FRAME RED C (#28400179) |
| 1 | 28400190 | FRAME BLACK (#28400190) |
| 1 | 28400191 | FRAME RED C (#28400191) |
| 2 | 19782520 | LOCK CYLINDER (#19782520) |
| 3 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 4 | 14109000 | BUSHING (#14109000) |
| 5 | 14609650 | TIE WRAP (#14609650) |
| 6 | 39103400 | RUBBER PAD FOR GAS TANK (#39103400) |
| 7 | 98054318 | BOLT (#98054318) |
| 8 | 39103500 | PLATE (#39103500) |
| 9 | 95021106 | WASHER, WAVE (#95021106) |
| 10 | 92630106 | NUT USE 92630707 (#92630106) |
| 11 | 28103260 | PIN (#28103260) |
| 12 | 95000208 | WASHER (#95000208) |
| 13 | 92660801 | CAGE NUT (#92660801) |
| 14 | 98613630 | SCREW (#98613630) |
| 15 | 95021112 | WASHER (#95021112) |
| 16 | 92602312 | NUT (#92602312) |
| 17 | 28429560 | FRONT ENGINE BOLT (#28429560) |
| 18 | 95001213 | WASHER A (#95001213) |
| 19 | 92601312 | NUT A (#92601312) |
| 20 | 93180080 | PLUG (#93180080) |
| 21 | 14418200 | BATTERY PLATE (#14418200) |
| 22 | 98054416 | BOLT (#98054416) |
| 23 | 95004208 | WASHER (#95004208) |
| 24 | 95021108 | WASHER (#95021108) |
| 25 | 92602208 | NUT (#92602208) |
| 26 | 28478360 | BRACKET A (#28478360) |
| 27 | 98054330 | BOLT (#98054330) |
| 28 | 91180613 | SPACER (#91180613) |
| 29 | 95000206 | WASHER (#95000206) |
| 30 | 28464360 | RH HANDLE (#28464360) |
| 31 | 28464361 | LH HANDLE A (#28464361) |
| 32 | 28462460 | 28462460 RH PLATE (#28462460) |
| 33 | 28462560 | LH PLATE (#28462560) |
| 34 | 27468720 | LOCK (#27468720) |
| 35 | 98054312 | BOLT (#98054312) |
| 36 | 92630105 | NUT (#92630105) |
| 37 | 28462060 | LOCK ASSY (#28462060) |
| 38 | 98612416 | ALLEN BOLT A (#98612416) |
| 39 | 95001208 | WASHER (#95001208) |
| 41 | 98612425 | SCREW (#98612425) |
| 43 | 95000205 | WASHER (#95000205) |
| 44 | 28666060 | #44 Plate (#28666060) |
| 45 | 92602206 | NUT (#92602206) USE STHN6MM |
| 46 | 91180605 | SPACER (#91180605) |
| 47 | 28109040 | BUFFER (#28109040) |
| 48 | 14494600 | CUP (#14494600) |
| 49 | 14516700 | SHIM (#14516700) |
| 50 | 14517000 | RING DUST SEAL (#14517000) |
