1983 1994 Le Mans 1000 Front Fork 1990
| Position | Part Number | Description |
|---|---|---|
| 1 | 28494090 | #01 Lower fork plate (#28494090) |
| 2 | 98620555 | ALLEN BOLT TREE (#98620555) |
| 3 | 95004210 | WASHER (#95004210) |
| 4 | 91181110 | BUSHING (#91181110) |
| 5 | 28493170 | STRG HEAD A (#28493170) |
| 6 | 98622535 | SCREW (#98622535) |
| 8 | 18516660 | BUSHING (#18516660) |
| 9 | 28522578 | RH SLIDER-BLACK B (#28522578) |
| 9 | 28522594 | FORK LEG RH B (#28522594) |
| 10 | 28522678 | LH SLIDER-BLACK (#28522678) |
| 10 | 28522694 | FORK LEG LH B (#28522694) |
| 11 | 98622316 | SCREW (#98622316) |
| 12 | 95100116 | WASHER (#95100116) |
| 13 | 29525450 | FORK TUBE EACH (#29525450) |
| 14 | 90403952 | FORK SEALS (#90403952) |
| 15 | 29524550 | WIPER RING (#29524550) |
| 16 | 29526460 | USE 29525360 FORK DAMPNER (#29526460) |
| 17 | 29526960 | TOP FORK SPRING (#29526960) |
| 18 | 29527960 | BUSHING (#29527960) |
| 19 | 29526650 | LOWER SPRINGS (#29526650) |
| 20 | ||
| 21 | 90706235 | O RING (#90706235) |
| 22 | 90706282 | O RING (#90706282) |
| 23 | 28490295 | #23 Front fork (#28490295) |
| 23 | 28490296 | #23 Front fork (#28490296) |
| 24 | 18513560 | SHIM (#18513560) |
| 25 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 26 | 98820540 | BOLT (#98820540) |
| 27 | 98622525 | BOLT (#98622525) |
| 28 | 29526360 | UPPER TUBE (#29526360) |
| 29 | 29526361 | LOWER TUBE (#29526361) |
| 30 | 92781100 | CAP NUT CHROME (#92781100) |
| 31 | 28526590 | NYLON WASHER (#28526590) |
| 32 | 95004217 | WASHER (#95004217) |
| 33 | 28513490 | #33 Nut (#28513490) |
| 34 | 28527633 | BUFFER (#28527633) |
