1983 1994 Le Mans 1000 Front Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 284343601 | #01 Front mudguard (#284343601) |
| 1 | 28434365 | FENDER--WHITE (#28434365) |
| 1 | 28434371 | FRONT FENDER,RED (#28434371) |
| 2 | 98230816 | SCREW (#98230816) |
| 3 | 28438760 | MUDFLAP A (#28438760) |
| 4 | 98054325 | BOLT (#98054325) |
| 5 | 93110060 | RUBBER WASHER (#93110060) |
| 6 | 95100141 | WASHER (#95100141) |
| 7 | 95100118 | WASHER (#95100118) |
| 8 | 92630106 | NUT USE 92630707 (#92630106) |
| 9 | 28437078 | REAR FENDER A (#28437078) |
| 10 | 28439178 | BRACKET A (#28439178) |
| 11 | 98622425 | ALLEN BOLT (#98622425) |
| 12 | 95021108 | WASHER (#95021108) |
| 13 | 92630508 | NUT (#92630508) |
| 14 | 90706092 | O RING (#90706092) |
| 15 | 28436460 | BUSHING A (#28436460) |
| 16 | 91551061 | GROMMET (#91551061) |
| 17 | 98054320 | BOLT (#98054320) |
| 18 | 19705900 | PLUG (#19705900) |
| 19 | 28659740 | GROMMET (#28659740) |
| 20 | 284344781 | #20 Front mudguard (#284344781) |
| 20 | 28434479 | FENDER RED (#28434479) |
| 20 | 28434490 | FT FENDER-BLACK C (#28434490) |
| 21 | 28436678 | PLATE (#28436678) |
| 22 | 98230830 | BOLT (#98230830) |
| 25 | 91180823 | FRONT SPACER (#91180823) |
| 26 | 91180825 | REAR SPACER (#91180825) |
| 27 | 91180818 | SPACER NLA (#91180818) |
| 28 | 28435578 | PLATE (#28435578) |
| 30 | 61270300 | WASHER (#61270300) |
| 31 | 28659778 | CABLE GUIDE (#28659778) |
