1983 1994 Le Mans 1000 Fuel Supply
| Position | Part Number | Description |
|---|---|---|
| 1 | 28115560 | MANIFOLD GASKET (#28115560) |
| 2 | 28115060 | MANIFOLD (#28115060) |
| 2 | 28115070 | INTAKE MANIFOLD - RH (#28115070) |
| 2 | 28115078 | #02 RH manifold (#28115078) |
| 3 | 28115061 | MANIFOLD (#28115061) |
| 3 | 28115071 | INTAKE MANIFOLD - L/H (#28115071) |
| 3 | 28115079 | #03 LH manifold (#28115079) |
| 4 | 98310610 | SCREW (#98310610) |
| 4 | 98310611 | SCREW (#98310611) |
| 5 | 95100116 | WASHER (#95100116) |
| 6 | 98612325 | BOLT (#98612325) |
| 6 | 98622325 | BOLT CHROME (#98622325) |
| 7 | 95004206 | WASHER (#95004206) |
| 8 | 28114360 | SLEEVE (#28114360) |
| 9 | 93305057 | CLAMP (#93305057) |
| 10 | 28112660 | CARBURETOR RH C (#28112660) |
| 10 | 28999577 | #11 Carburettor LH (#28999577) |
| 11 | 28112661 | CARBURETOR LH C (#28112661) |
| 12 | 28133560 | CHOKE CABLE (#28133560) |
| 13 | 28134060 | CHOKE CABLE LM 1000 (#28134060) |
| 14 | 17133151 | STARTER DEVICE (#17133151) |
| 15 | 28135660 | PLATE (#28135660) |
| 16 | 95021105 | LOCK WASHER (#95021105) |
| 17 | 98074216 | #28 Screw (#98074216) |
