1983 1994 Le Mans 1000 Fuel Tank
| Position | Part Number | Description |
|---|---|---|
| 1 | 281002601 | FUEL TANK (#281002601) USE 28100270 |
| 1 | ||
| 1 | 28100262 | FUEL-TANK -WHITE 28100262 (#28100262) |
| 1 | ||
| 1 | 28100278 | FUEL TANK (#28100278) |
| 1 | 28100290 | FUEL-TANK Lemans 1000 28100290 (#28100290) |
| 1 | 28100291 | GAS TANK BLACK C (#28100291) |
| 2 | 28106460 | USE 823931070 (#28106460) |
| 3 | 14103955 | GAS CAP (#14103955) |
| 4 | 28104061 | COVER RED (#28104061) |
| 4 | 28104062 | COVER-WHITE (#28104062) |
| 4 | 28104091 | TANK LID BLACK (#28104091) |
| 4 | 611040601 | #44 Fuel filler cap cover (#611040601) |
| 5 | 14736856 | LOCK W/ KEY (#14736856) |
| 6 | 18105001 | LATCH (#18105001) |
| 7 | 19104950 | RETAINER (#19104950) |
| 8 | 19104336 | GROMMET (#19104336) |
| 9 | 98054210 | BOLT (#98054210) |
| 10 | 95129100 | WASHER (#95129100) |
| 11 | 29106500 | FUEL PIPE (#29106500) USE 29106551 |
| 12 | 28108410 | HOSE CLAMP (#28108410) |
| 13 | 28105460 | PETCOCK LM SE RH (#28105460) |
| 14 | 28105461 | PETCOCK LMSE LH (#28105461) |
| 15 | 91551131 | GROMMET (#91551131) |
| 16 | 28923360 | DECAL SET GOLD/BLACK USE 2892 3370 (#28923360) |
| 16 | 28923370 | DECAL SET (#28923370) |
