1983 1994 Le Mans 1000 Rear Master Cylinder
| Position | Part Number | Description |
|---|---|---|
| 1 | 28677060 | BRAKE LEVER (#28677060) |
| 2 | 14251001 | SHIFT AND BRAKE PEDAL RUBBER (#14251001) |
| 3 | 90706141 | O RING (#90706141) USE 847180 |
| 4 | 95004215 | WASHER (#95004215) |
| 5 | 95500227 | COTTER PIN (#95500227) |
| 6 | 95740175 | FORK CHROME (#95740175) |
| 7 | 92690073 | NUT (#92690073) |
| 8 | 19675100 | ROD (#19675100) |
| 9 | 95770265 | PIN (#95770265) |
| 10 | 95129110 | WASHER (#95129110) |
| 11 | 95500222 | SPLIT PIN (#95500222) |
| 12 | 31666990 | MASTER CYL ASSY (#31666990) |
| 13 | 28667560 | LEVER (#28667560) |
| 14 | 19667600 | SPRING (#19667600) |
| 15 | 98202525 | SCREW (#98202525) |
| 16 | 92602205 | NUT (#92602205) |
| 17 | 28668046 | BRAKE BLOCK (#28668046) |
| 17 | 28668578 | BRAKE VALVE (#28668578) |
| 18 | 17093850 | CABLE BOOT (#17093850) |
| 19 | 17659350 | Rear Master Cylinder Kit (Front for T) (#17659350) |
| 20 | 28665060 | BRAKE RESERVOIR (#28665060) |
| 21 | 98326009 | SCREW (#98326009) |
| 22 | 93301175 | CABLE CLAMP (#93301175) |
| 23 | 95985624 | TUBE A (#95985624) |
| 24 | 19157800 | CLAMP COMPLETE (#19157800) |
| 25 | 63657000 | BRAKE LIGHT SWITCH (#63657000) |
| 26 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 27 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 28 | 95000206 | WASHER (#95000206) |
| 29 | 28658560 | BRAKE HOSE (#28658560) |
| 30 | 95990028 | SCREW (#95990028) |
| 32 | 18667450 | Brake reservoir cap (#18667450) |
| 33 | 19659500 | REV KIT (#19659500) |
| 34 | 19659600 | PIN KIT (#19659600) |
| 35 | 92602206 | NUT (#92602206) USE STHN6MM |
