1983 1994 Le Mans 1000 Saddle Side Panels
| Position | Part Number | Description |
|---|---|---|
| 1 | 284762601 | #01 RH side panel (#284762601) |
| 1 | 28476261 | RH COVER-RED B USE 2847 6270 (#28476261) |
| 1 | 28476262 | RH COVER-WHITE B USE 2847 6270 (#28476262) |
| 1 | 28476270 | RH COVER B (#28476270) |
| 1 | 28476278 | RH SIDE TYPE B C (#28476278) |
| 1 | 28476290 | RH COVER C (#28476290) |
| 1 | 28476291 | RH SIDE BLACK B (#28476291) |
| 2 | 284763601 | #02 LH side panel (#284763601) |
| 2 | 28476361 | LH COVER-RED B MORE C8G1 (#28476361) |
| 2 | 28476362 | LH COVER-WHITE B (#28476362) |
| 2 | 28476370 | COVER LH-R & W B (#28476370) |
| 2 | 28476378 | LH SIDE TYPE B C (#28476378) |
| 2 | 28476390 | LH COVER C (#28476390) |
| 2 | 28476391 | LH SIDE BLACK B (#28476391) |
| 3 | 98326014 | SCREW (#98326014) |
| 4 | 93110060 | RUBBER WASHER (#93110060) |
| 5 | 92660601 | CAGE NUT (#92660601) |
| 6 | 27573820 | FELT SPACER (#27573820) |
| 7 | 27573821 | SPACER (#27573821) |
| 8 | 28574660 | BRACKET (#28574660) |
| 9 | 28460560 | SEAT LM 4 (#28460570) USE 2846 0560 (#28460560) |
| 9 | 28460577 | SEAT (#28460577) USE 28460560 |
| 10 | 27461820 | PLUG (#27461820) |
| 11 | 28479960 | RUBBER SEAL (#28479960) |
| 12 | 28462960 | PIN (#28462960) |
| 13 | 28478560 | PIN (#28478560) |
| 14 | 95000205 | WASHER (#95000205) |
| 15 | 92602205 | NUT (#92602205) |
| 16 | 28922262 | SPACER (#28922262) |
