1985 1987 V 35 III 350 Foot Rests Lateral Stand
| Position | Part Number | Description |
|---|---|---|
| 1 | 23420380 | RH craddle arm (#23420380) |
| 2 | 23422180 | LH craddle arm (#23422180) |
| 3 | 19430305 | CENTER STAND (#19430305) |
| 4 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 5 | 12434001 | SPRING (#12434001) |
| 6 | 98054530 | BOLT (#98054530) |
| 7 | 91181114 | SPACER (#91181114) |
| 8 | 94322215 | SPRING-ROCKER (#94322215) |
| 9 | 95000210 | WASHER (#95000210) |
| 10 | 92630510 | NUT (#92630510) |
| 11 | 19432060 | SIDE ARM (#19432060) |
| 12 | 19433000 | PLUG (#19433000) |
| 13 | 99105129 | BOLT (#99105129) |
| 14 | 19434000 | SPRING (#19434000) |
| 18 | 28440710 | RF ARM (#28440710) |
| 19 | 28441810 | foot peg bracket (#28441810) |
| 20 | 95129115 | WASHER (#95129115) |
| 21 | 98074430 | BOLT BLACK (#98074430) |
| 22 | 61270300 | WASHER (#61270300) |
| 23 | 92601210 | NUT (#92601210) |
| 24 | 28443201 | 28443201 Rubber pedal (#28443201) |
| 25 | 27447520 | FOOT CATCH (#27447520) |
| 26 | 27442320 | REAR FOOTREST (#27442320) |
| 27 | 98231025 | BOLT (#98231025) |
| 28 | 14018400 | WASHER (#14018400) |
| 31 | 19017000 | BUSH (#19017000) |
| 32 | 53429500 | BOLT (#53429500) |
| 33 | 95004210 | WASHER (#95004210) |
| 34 | 92602210 | NUT (#92602210) |
| 35 | 98052565 | BOLT (#98052565) |
| 38 | 98054322 | BOLT (#98054322) |
| 39 | 92602206 | NUT (#92602206) USE STHN6MM |
| 40 | 92601208 | NUT (#92601208) |
