1985 1988 850 T5 III Civilian Electrical System
| Position | Part Number | Description |
|---|---|---|
| 1 | 17743000 | FUSE BLOCK (#17743000) |
| 2 | 98202530 | SCREW (#98202530) |
| 3 | 17743100 | COVER NLA (#17743100) |
| 4 | 95000205 | WASHER (#95000205) |
| 5 | 92630105 | NUT (#92630105) |
| 6 | 17742550 | FUSE 16 AMP (#17742550) |
| 7 | 28747140 | WIRING HARNESS (#28747140) |
| 8 | 19732400 | COUPLING (#19732400) |
| 9 | 14756152 | CONN (#14756152) |
| 10 | 28727200 | RESISTANCE (#28727200) |
| 11 | 28747200 | #11 Dashboard cable (#28747200) |
| 12 | 14756251 | SOCKET (#14756251) |
| 13 | 17756000 | COVER (#17756000) |
| 14 | 14747455 | CABLE ASSY (#14747455) |
| 15 | 17755860 | 4 PIN CONNECTOR (#17755860) |
| 16 | 17755783 | #16 Cap (#17755783) |
| 17 | 28747350 | CABLE (#28747350) |
| 18 | 14609650 | TIE WRAP (#14609650) |
| 19 | 49609601 | TIE STRAP (#49609601) |
| 20 | 28726300 | WIRING HARNESS (#28726300) |
| 21 | 61712500 | CONNECTOR (#61712500) |
| 22 | 61712600 | CONNECTOR (#61712600) |
| 23 | 17750520 | TURN SIGNAL FLASHER (#17750520) |
| 24 | 17751200 | FLASHER HOLDER (#17751200) |
| 25 | 17750400 | RELAY BRACKET (#17750400) |
| 26 | 12735100 | CAP (#12735100) |
| 27 | 12717600 | Cap (#12717600) |
| 28 | 17756160 | CONNECTION (#17756160) |
| 29 | 17756060 | CAP (#17756060) |
| 30 | 65723001 | CONNECTOR (#65723001) |
| 31 | 14756150 | CONNECTION (#14756150) |
| 32 | 14756250 | CONNECTOR (#14756250) |
| 33 | 18720150 | CABLES (#18720150) |
