1985 1988 850 T5 III Civilian Rear Master Cylinder
| Position | Part Number | Description |
|---|---|---|
| 1 | 28676548 | BRAKE LEVER ASSY (#28676548) |
| 2 | 28252010 | BUSHING (#28252010) |
| 3 | 14251001 | SHIFT AND BRAKE PEDAL RUBBER (#14251001) |
| 4 | 98054320 | BOLT (#98054320) |
| 5 | 92602206 | NUT (#92602206) USE STHN6MM |
| 6 | 30252360 | PIVOT BOLT A USE 17252350 (#30252360) |
| 7 | 28659740 | GROMMET (#28659740) |
| 8 | 95100409 | WASHER (#95100409) |
| 9 | 92701120 | NUT (#92701120) |
| 10 | 17675050 | ROD COMPL. (#17675050) |
| 11 | 95740175 | FORK CHROME (#95740175) |
| 12 | 92700073 | NUT (#92700073) |
| 13 | 17675150 | ROD LINKAGE (#17675150) |
| 14 | 95770265 | PIN (#95770265) |
| 15 | 95129110 | WASHER (#95129110) |
| 16 | 95500222 | SPLIT PIN (#95500222) |
| 17 | 95100173 | WASHER (#95100173) |
| 18 | 95129130 | SHAKE PROOF WASHER (#95129130) |
| 19 | 29667000 | MASTER CYL REAR (#29667000) |
| 20 | 18667450 | Brake reservoir cap (#18667450) |
| 21 | 17667551 | LEVER (#17667551) |
| 22 | 17667651 | SPRING (#17667651) |
| 23 | 98620440 | SCREW (#98620440) |
| 24 | 95021108 | WASHER (#95021108) |
| 25 | 92602208 | NUT (#92602208) |
| 26 | 28668046 | BRAKE BLOCK (#28668046) |
| 27 | 63657000 | BRAKE LIGHT SWITCH (#63657000) |
| 28 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 29 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 30 | 95000206 | WASHER (#95000206) |
| 31 | 28658500 | REAR BRAKE HOSE (#28658500) |
| 32 | 28657500 | HOSE A (#28657500) |
| 33 | 95990028 | SCREW (#95990028) |
| 34 | 91551131 | GROMMET (#91551131) |
| 35 | 28415500 | SUPPORT PLATE (28415500) (#28415500) |
| 36 | 12735100 | CAP (#12735100) |
| 37 | 28652301 | CALIPER RH (#28652301) |
| 38 | 98054525 | BOLT (#98054525) |
| 39 | 95129180 | WAVE WASHER (#95129180) |
| 40 | 14498550 | PLUG (#14498550) |
| 41 | 28635800 | BRACKET (#28635800) |
| 42 | 28658700 | BRAKE PIPE (#28658700) |
| 43 | 17659650 | TUBE (#17659650) |
| 44 | 14609650 | TIE WRAP (#14609650) |
| 45 | 28659700 | RING OR CABLE GUIDE (#28659700) |
| 46 | 91551120 | GROMMET (#91551120) |
| 48 | 92630106 | NUT USE 92630707 (#92630106) |
| 49 | 28655700 | CABLE GUIDE (#28655700) |
| 51 | 28658840 | BRAKE HOSE (#28658840) |
| 53 | 95100332 | SHIM 0.5 MM (#95100332) |
| 53 | 95100333 | SHIM 0.8 MM (#95100333) |
| 54 | 17659350 | Rear Master Cylinder Kit (Front for T) (#17659350) |
| 55 | 14659450 | REV.KIT (#14659450) |
| 56 | 17654760 | COVER (#17654760) |
| 57 | 28654601 | (#28654601) |
| 58 | 14659000 | CALIPER KIT (#14659000) |
| 59 | 14659100 | BRAKE PINS KIT 2 PER BAG (#14659100) |
| 60 | 17659260 | BLEEDER SCREW KIT (#17659260) |
| 61 | 90706108 | O RING (#90706108) |
| 62 | 17093850 | CABLE BOOT (#17093850) |
