1985 1989 850 T5 Police Foot Rests Lateral Stand
| Position | Part Number | Description |
|---|---|---|
| 1 | 17420350 | ARM (#17420350) |
| 2 | 17422181 | CRADDLE (#17422181) |
| 3 | 95000213 | WASHER (#95000213) |
| 4 | 95004208 | WASHER (#95004208) |
| 5 | 98054416 | BOLT (#98054416) |
| 6 | 14418200 | BATTERY PLATE (#14418200) |
| 7 | 92602208 | NUT (#92602208) |
| 8 | 95021108 | WASHER (#95021108) |
| 9 | 14432900 | PLATE USE 03432970 RH (#14432900) |
| 10 | 14433200 | PLATE USE 0343 3270 LH (#14433200) |
| 11 | 18434060 | CENTERSTAND SPRING (#18434060) |
| 12 | 14433500 | BUSHING (#14433500) |
| 13 | 98052545 | SCREW (#98052545) |
| 14 | 95004210 | WASHER (#95004210) |
| 15 | 14433400 | WASHER (#14433400) |
| 16 | 92630110 | NUT (#92630110) |
| 17 | 28430345 | #17 Central stand (#28430345) |
| 18 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 19 | 28432045 | #19 Lateral stand (#28432045) |
| 21 | 12433000 | BUFFER-CENTER STAND STOP (#12433000) |
| 22 | 29432800 | PLATE (#29432800) |
| 23 | 92781100 | CAP NUT CHROME (#92781100) |
| 24 | 18432760 | PLATE (#18432760) |
| 25 | 14434000 | SPRING (#14434000) |
| 26 | 13433440 | SUPPORT (#13433440) |
| 27 | 98052440 | BOLT (#98052440) |
| 30 | 28446045 | #30 LH footrest (#28446045) |
| 31 | 18443680 | FOOTPEG RH A (#18443680) |
| 32 | 14443200 | FOOT PEG RUBBER (#14443200) |
| 33 | 17455945 | Stand support (#17455945) |
| 34 | 14429500 | BOLT (ROD) (#14429500) |
| 36 | 92602312 | NUT (#92602312) |
| 37 | 14429600 | BOLT (#14429600) |
| 38 | 14429900 | SPACER (#14429900) |
| 39 | 14429800 | SPACER (#14429800) |
| 42 | 98623630 | SCREW (#98623630) |
| 43 | 98623635 | SCREW USE 9881 3635 (#98623635) |
| 44 | 95021112 | WASHER (#95021112) |
| 45 | 92602512 | NUT (#92602512) |
| 47 | 18759351 | SUPPORT (#18759351) |
| 48 | 98054320 | BOLT (#98054320) |
| 49 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 50 | 91180607 | SPACER (#91180607) |
| 51 | 95100139 | WASHERS (#95100139) |
| 52 | 93301313 | BRACKET (#93301313) |
| 53 | 29755400 | SIDE STAND SWITCH (#29755400) |
