1986 1990 V 35 Florida 350 Instruments
| Position | Part Number | Description |
|---|---|---|
| 1 | 23760010 | HOUSING (#23760010) |
| 2 | 23761510 | #02 Speedometer (#23761510) |
| 3 | 23768310 | ANGLE DRIVE (#23768310) |
| 4 | 23767210 | #04 Tachometer (#23767210) |
| 5 | 23761910 | TACH HSG (#23761910) |
| 6 | 23762010 | SPEEDO HSG NLA 6/18/02 (#23762010) |
| 7 | 98290520 | SCREW (#98290520) |
| 8 | 23765110 | SPACER A (#23765110) |
| 9 | 23764910 | PLATE (#23764910) |
| 10 | 14768650 | BULB SOCKET A (#14768650) |
| 11 | 93450120 | BULB ALL GLASS (#93450120) |
| 12 | 27760410 | SPEEDO CABLE (#27760410) |
| 13 | 23766510 | PLATE (#23766510) |
| 14 | 27768120 | #14 Rev counter transmission (#27768120) |
| 15 | 29765250 | LOWER COVER (#29765250) |
| 16 | 99210210 | SCREW (#99210210) |
| 17 | 19768680 | BULB HOLDER (#19768680) |
| 18 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 19 | 23764110 | BRACKET A (#23764110) |
| 20 | 23766911 | SPACER (#23766911) |
| 21 | 98054225 | BOLT(#98054225) |
| 22 | 95004205 | WASHER (#95004205) |
| 23 | 98054320 | BOLT (#98054320) |
| 24 | 95004206 | WASHER (#95004206) |
| 25 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 26 | 91180607 | SPACER (#91180607) |
| 27 | 92602206 | NUT (#92602206) USE STHN6MM |
| 28 | 28745760 | HAZARD SWITCH A (#28745760) |
| 29 | 35755780 | RUBBER BOOT (#35755780) |
| 30 | 93110060 | RUBBER WASHER (#93110060) |
| 31 | 98054230 | BOLT (#98054230) |
| 32 | 23766910 | SPACER A (#23766910) |
| 33 | 95100118 | WASHER (#95100118) |
