1986 1992 V 65 Florida 650 Mudguards
| Position | Part Number | Description |
|---|---|---|
| 1 | 23434210 | FRT FENDER (#23434210) |
| 2 | 27436920 | #02 Splash guard (#27436920) |
| 4 | 28659740 | GROMMET (#28659740) |
| 5 | 92602208 | NUT (#92602208) |
| 6 | 61270300 | WASHER (#61270300) |
| 7 | 19438770 | #07 Splash guard (#19438770) |
| 8 | 98054325 | BOLT (#98054325) |
| 9 | 95100118 | WASHER (#95100118) |
| 10 | 93110060 | RUBBER WASHER (#93110060) |
| 11 | 95100141 | WASHER (#95100141) |
| 12 | 92630106 | NUT USE 92630707 (#92630106) |
| 13 | 19705900 | PLUG (#19705900) |
| 14 | 23437010 | #14 Rear mudguard (#23437010) |
| 15 | 91551099 | RUBBER (#91551099) |
| 16 | 23438980 | GASKET (#23438980) |
| 18 | 98054320 | BOLT (#98054320) |
| 19 | 95000206 | WASHER (#95000206) |
| 20 | 28929940 | TOOL KIT 14929955 (#28929940) |
| 21 | 14912755 | SHOCK ADJ TOOL A (#14912755) |
| 22 | 23900010 | #22 Operator's handbook (#23900010) |
| 22 | 23900011 | Operator's handbook (#23900011) |
| 22 | 23900012 | Operator's handbook (#23900012) |
| 22 | 23900013 | #22 Operator's handbook (#23900013) |
| 23 | 23439210 | #31 Plate (#23439210) |
| 24 | 23439010 | #30 Control unit fixing plate (#23439010) |
| 25 | 23438510 | #29 Holder (#23438510) |
| 26 | 98054312 | BOLT (#98054312) |
