1986 1992 V 65 Florida 650 Windscreen Front Bumpers
| Position | Part Number | Description |
|---|---|---|
| 1 | 23577270 | #01 Windscreen (#23577270) |
| 2 | 66506820 | Windscreen support (#66506820) |
| 3 | 23506810 | #03 RH clamp (#23506810) |
| 4 | 23506910 | #04 LH clamp (#23506910) |
| 5 | 95004210 | WASHER (#95004210) |
| 6 | 98622535 | SCREW (#98622535) |
| 7 | 23943510 | CHROME PLUG (#23943510) |
| 8 | 92630510 | NUT (#92630510) |
| 9 | 98326016 | SCREW, PAN HEAD (#98326016) |
| 10 | 93110060 | RUBBER WASHER (#93110060) |
| 11 | 95100119 | WASHER (#95100119) |
| 12 | 23576910 | #12 Rubber spacer (#23576910) |
| 13 | 23450210 | SAFETY BAR ASSY A (#23450210) |
| 14 | 23447610 | #14 RH footrest (#23447610) |
| 15 | 23447710 | #15 LH footrest (#23447710) |
| 16 | 98622545 | ALLEN BOLT (#98622545) |
| 17 | 95120105 | WASHER (#95120105) |
| 18 | 92602210 | NUT (#92602210) |
| 19 | 98620350 | ALLEN BOLT (#98620350) |
| 20 | 95004206 | WASHER (#95004206) |
| 21 | 92630106 | NUT USE 92630707 (#92630106) |
| 22 | 17530260 | STEERING DAMPER (#17530260) |
| 23 | 23531860 | SPECIAL BRACKET V65 (#23531860) |
| 24 | 91180618 | SPACER (#91180618) |
| 25 | 98620340 | SCREW (#98620340) |
| 26 | 95000206 | WASHER (#95000206) |
| 28 | 98620345 | SCREW (#98620345) |
| 29 | 98622425 | ALLEN BOLT (#98622425) |
| 30 | 95021108 | WASHER (#95021108) |
| 31 | 95000208 | WASHER (#95000208) |
| 32 | 92602208 | NUT (#92602208) |
| 33 | 98072570 | BOLT (#98072570) |
| 34 | 23451170 | #31 Spacer (#23451170) |
