1987 1989 65 GT 650 Front Rear Mudguards
| Position | Part Number | Description |
|---|---|---|
| 1 | 28434300001 | #01 Front mudard (#28434300001) |
| 2 | 98230845 | ALLEN BOLT (#98230845) |
| 3 | 27436920 | #02 Splash guard (#27436920) |
| 4 | 28659740 | GROMMET (#28659740) |
| 5 | 27438635 | REAR PANEL A (#27438635) |
| 6 | 98054320 | BOLT (#98054320) |
| 7 | 93110060 | RUBBER WASHER (#93110060) |
| 8 | 95000206 | WASHER (#95000206) |
| 9 | 95100141 | WASHER (#95100141) |
| 10 | 92630106 | NUT USE 92630707 (#92630106) |
| 11 | 19705900 | PLUG (#19705900) |
| 12 | 27437085 | FENDER REAR A (#27437085) |
| 13 | 95008206 | WASHER (#95008206) |
| 14 | 93110082 | RUBBER WASHER (#93110082) |
| 16 | 27474385 | #16 Rear headlight supp. (#27474385) |
| 17 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 18 | 91180607 | SPACER (#91180607) |
| 20 | 234726301 | #20 Rear fairing (#234726301) |
| 21 | 98290516 | BOLT (#98290516) |
| 23 | 27462085 | #23 Covers assy (#27462085) |
| 24 | 92602205 | NUT (#92602205) |
| 25 | 95000205 | WASHER (#95000205) |
| 26 | 92660501 | CAGE NUT (#92660501) |
| 27 | ||
| 28 | 27468720 | LOCK (#27468720) |
| 29 | 98290511 | SCREW (#98290511) |
| 31 | 91551092 | #04 Grommet (#91551092) |
| 32 | 23450210 | SAFETY BAR ASSY A (#23450210) |
| 33 | 98622420 | ALLEN BOLT A (#98622420) |
| 34 | 95021108 | WASHER (#95021108) |
| 35 | 95004208 | WASHER (#95004208) |
| 36 | 92602208 | NUT (#92602208) |
| 37 | ||
| 38 | 98052220 | BOLT (#98052220) |
| 39 | 90716057 | FAIRING O RING (#90716057) |
| 40 | 95100059 | WASHER (#95100059) |
| 41 | 92630105 | NUT (#92630105) |
| 42 | 90706092 | O RING (#90706092) |
| 43 | 23436440 | #43 Bush (#23436440) |
| 44 | 23464430 | #35 Pillion grab bar (#23464430) |
| 45 | 27900035 | #45 Operator's handbook (#27900035) |
| 47 | 274366201 | #11 Plate (#274366201) |
| 48 | 23436540 | #48 Stud bolt (#23436540) |
| 49 | 98054420 | BOLT (#98054420) |
| 50 | 95000208 | WASHER (#95000208) |
| 51 | 61270300 | WASHER (#61270300) |
