1987 1990 NTX 350 Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 271002151 | #01 Fuel tank (#271002151) |
| 2 | 66103915 | #02 Fuel filler cap (#66103915) |
| 3 | 66109715 | #03 Breather pipe (#66109715) |
| 4 | 66101815 | #04 Union (#66101815) |
| 5 | 90706204 | #05 Ring (#90706204) |
| 6 | 27105410 | RH PETCOCK A (#27105410) |
| 8 | 29106500 | FUEL PIPE (#29106500) USE 29106551 |
| 9 | 61108400 | CLAMP (#61108400) |
| 10 | 61108500 | CLIP (#61108500) |
| 11 | 27103515 | #30 Plate (#27103515) |
| 12 | 27103415 | #28 Rubber spacer (#27103415) |
| 13 | 27460515 | #13 Saddle (#27460515) |
| 14 | 27460910 | RH BRACKET (#27460910) |
| 15 | 27460911 | LH BRACKET (#27460911) |
| 16 | 91180605 | SPACER (#91180605) |
| 17 | 27462910 | #17 Knob (#27462910) |
| 18 | 92660601 | CAGE NUT (#92660601) |
| 19 | 274664101 | #19 Rear fairing (#274664101) |
| 19 | 27466416 | #19 Rear fairing (#27466416) |
| 19 | 27466417 | #19 Rear fairing (#27466417) |
| 19 | 27466418 | #19 Rear fairing (#27466418) |
| 20 | 274762151 | #20 RH side panel (#274762151) |
| 21 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 22 | 66478610 | WASHER (#66478610) |
| 23 | 98326016 | SCREW, PAN HEAD (#98326016) |
| 24 | 274763151 | #24 LH side panel (#274763151) |
| 25 | 27923315 | #25 Decal set (#27923315) |
| 27 | 98250516 | SCREW (#98250516) |
| 28 | 98622430 | SCREW (#98622430) |
| 29 | 92660801 | CAGE NUT (#92660801) |
| 30 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 31 | 95021106 | WASHER, WAVE (#95021106) |
| 32 | 95101140 | WASHER A (#95101140) |
