1987 1990 NTX 350 Electrical System
| Position | Part Number | Description |
|---|---|---|
| 1 | 27747115 | #01 Electrical system (#27747115) |
| 2 | 19732500 | HORN, HL OR STARTER RELAY (#19732500) |
| 3 | 98054212 | BOLT (#98054212) |
| 4 | 95000205 | WASHER (#95000205) |
| 5 | 92602205 | NUT (#92602205) |
| 6 | 28750561 | FLASHER A (#28750561) |
| 7 | 27725810 | WIRING HARNESS (#27725810) |
| 8 | 27747215 | #08 Dashboard cable (#27747215) |
| 9 | 27722115 | #09 Ignition harness (#27722115) |
| 10 | 23721494 | #20 Electronic control unit (#23721494) |
| 11 | 27723835 | SUPPORT (#27723835) |
| 12 | 27710435 | CONDENSER A (#27710435) |
| 13 | 62747320 | CABLE HARNESS (#62747320) |
| 14 | 27747815 | #14 Wire (#27747815) |
| 15 | 30743000 | FUSE BOX ASSY A (#30743000) |
| 16 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 17 | 39741150 | #29 Brake light switch (#39741150) |
| 18 | 92700071 | NUT (#92700071) |
| 19 | 19724560 | OIL SENDER WIRE A (#19724560) |
| 20 | 18759550 | CABLE (#18759550) |
| 21 | 14609650 | TIE WRAP (#14609650) |
| 21 | 61609630 | #26 Hose clamp (#61609630) |
| 22 | 14747455 | CABLE ASSY (#14747455) |
| 23 | 23726300 | #23 Alternator wiring BOSCH (#23726300) |
| 24 | 95021105 | LOCK WASHER (#95021105) |
| 25 | 98054216 | SCREW (#98054216) |
| 26 | 95100059 | WASHER (#95100059) |
| 28 | 92630205 | LOCK NUT (#92630205) |
