1987 1990 NTX 350 Front Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 27490215 | #01 Front fork (#27490215) |
| 1 | 27490216 | #01 Front fork (#27490216) |
| 2 | 31999236 | Shock absorber-pair (#31999236) |
| 3 | 23555281 | PIN (#23555281) |
| 4 | 23555280 | STUD (#23555280) |
| 5 | 91181407 | SPACER (#91181407) |
| 6 | 95007210 | WASHER (#95007210) |
| 7 | 98832420 | #07 Screw (#98832420) |
| 8 | ||
| 9 | 98830416 | #09 Screw (#98830416) |
| 10 | 92602411 | NUT (#92602411) |
| 11 | 27530532 | RR.SHOCK BUSHING (#27530532) |
| 12 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 13 | 14516700 | SHIM (#14516700) |
| 14 | 14517000 | RING DUST SEAL (#14517000) |
| 15 | 95100256 | WASHER (#95100256) |
| 16 | 27504915 | #16 Spacer (#27504915) |
| 17 | 27658415 | #17 Cable-'ide (#27658415) |
| 18 | 27658215 | #18 Ring (#27658215) |
| 19 | 98620335 | SCREWS (#98620335) |
| 20 | 91180802 | SPACER (#91180802) |
| 21 | 98620440 | SCREW (#98620440) |
| 22 | 95022110 | Washer (#95022110) |
