1987 1990 NTX 350 Handlebar
| Position | Part Number | Description |
|---|---|---|
| 1 | 27600315 | #01 Handlebar (#27600315) |
| 2 | 30605530 | CLUTCH LEVER ASSY #30605530) (#30605530) |
| 3 | 27659415 | CHOKE LEVER ASSY (#27659415) |
| 5 | 27601015 | HALF CLAMP (#27601015) |
| 6 | 27601215 | ALLEN BOLT BLACK (#27601215) |
| 7 | 30602500 | ADJUSTER ASSY (#30602500)USE AP8118348 |
| 8 | 27663815 | CABLE BOOT (#27663815) |
| 9 | 27738015 | SWITCH (#27738015) |
| 10 | 19999415 | GRIP SET (#19999415) |
| 11 | 27093015 | Clutch Cable (#27093015) |
| 12 | 27117515 | Throttle cable (#27117515) |
| 13 | 30607910 | CABLE SPLITTER (#30607910) |
| 14 | 27117775 | Throttle cable (#27117775) |
| 16 | 27603815 | THROTTLE TUBE (#27603815) |
| 17 | 27604415 | GUIDE BLOCK (#27604415) |
| 18 | 27738815 | STARTER SWITCH (27738815) (#27738815) |
| 19 | 27603715 | ADJUSTER (#27603715) |
| 20 | 27117615 | BOOT (#27117615) |
| 21 | 27769475 | #21 Rearview mirror (#27769475) |
| 22 | 28929940 | TOOL KIT 14929955 (#28929940) |
| 23 | 19912700 | TOOL (#19912700) |
| 24 | 27900015 | #24 Operator's handbook (#27900015) |
| 24 | 27900016 | #24 Operator's handbook (#27900016) |
| 24 | 27900017 | #24 Operator's handbook (#27900017) |
| 24 | 27900018 | #24 Operator's handbook (#27900018) |
