1987 1990 NTX 650 Air Filter
| Position | Part Number | Description |
|---|---|---|
| 1 | 19114060 | FILTER HOUSING (#19114060) |
| 2 | 28113650 | AIR FILTER CA II, LM 1000, SPII & OTHERS (#28113650) |
| 3 | 19112960 | BRACKET (#19112960) |
| 4 | 19113960 | GASKET (#19113960) |
| 5 | 19111060 | PROTECTION (#19111060) |
| 6 | 19111160 | COVER (#19111160) |
| 7 | 19113760 | COVER (#19113760) |
| 8 | 19110760 | RUBBER - USE 30110715 (#19110760) |
| 9 | 19113460 | FILTER BOX UPPR (#19113460) |
| 10 | 19110860 | RUBBER - USE 31110815 (#19110860) |
| 11 | 27114160 | BRACKET (#27114160) |
| 12 | 98054214 | BOLT (#98054214) |
| 13 | 95021105 | LOCK WASHER (#95021105) |
| 14 | 95000205 | WASHER (#95000205) |
| 15 | 92670305 | WING NUT (#92670305) |
| 16 | 27153460 | BREATHER TANK USE 31153481 (#27153460) |
| 17 | 23159670 | #17 Breather (#23159670) |
| 18 | 93305018 | CLAMP A (#93305018) |
| 19 | 61108400 | CLAMP (#61108400) |
| 20 | 27159360 | HOSE USE 32159310 (#27159360) |
| 21 | 27157420 | USE 30157430 (#27157420) |
| 22 | 27111271 | #24 Guard (#27111271) |
| 23 | 99200413 | SCREW (#99200413) |
| 24 | 19433000 | PLUG (#19433000) |
| 25 | 14423800 | RUBBER (#14423800) |
