1987 1990 NTX 650 Fuel Supply
| Position | Part Number | Description |
|---|---|---|
| 1 | 27112677 | #01 Carburettor RH (#27112677) |
| 2 | 27112676 | #02 Carburettor LH (#27112676) |
| 3 | 23115070 | #03 RH intake manifold (#23115070) |
| 4 | 23115071 | #04 LH intake manifold (#23115071) |
| 5 | 19115580 | INTAKE GASKET (#19115580) |
| 6 | 98310611 | SCREW (#98310611) |
| 7 | 95100116 | WASHER (#95100116) |
| 8 | 98812325 | #08 Screw (#98812325) |
| 9 | 61013800 | SPRING WASHER (#61013800) |
| 10 | 19114360 | INTAKE SLEEVE USE 31114383 (#19114360) |
| 11 | 93305032 | CLAMP (#93305032) |
| 12 | 19114680 | RING (#19114680) |
| 13 | 19114460 | AIR INTAKE (#19114460) |
| 14 | 39607900 | CABLE SPLITTER (#39607900) USE 30607910 |
| 15 | 27132815 | #22 Choke cable (#27132815) |
| 16 | 27133515 | #13 Choke cable (#27133515) |
| 17 | 19718000 | CLAMP (#19718000) |
| 18 | 93305045 | CLAMP (#93305045) USE 93305032 |
| 19 | 93305052 | #19 Hose clamp (#93305052) |
