1987 1991 GT 1000 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 28400133 | #01 Frame (#28400133) |
| 1 | 28400134 | #01 Frame (#28400134) |
| 1 | 28400135 | #01 Frame (#28400135) |
| 2 | 39103400 | RUBBER PAD FOR GAS TANK (#39103400) |
| 3 | 98054325 | BOLT (#98054325) |
| 4 | 39103500 | PLATE (#39103500) |
| 5 | 91180612 | #05 Spacer (#91180612) |
| 6 | 95004206 | WASHER (#95004206) |
| 7 | 92630106 | NUT USE 92630707 (#92630106) |
| 8 | 14109000 | BUSHING (#14109000) |
| 9 | 28109040 | BUFFER (#28109040) |
| 10 | 14609650 | TIE WRAP (#14609650) |
| 11 | 28782550 | LOCK (#28782550) |
| 12 | 28749733 | RH PLATE (#28749733) |
| 13 | 93180080 | PLUG (#93180080) |
| 14 | 29461450 | RUBBER PAD (#29461450) |
| 15 | 30716710 | PLATE A (#30716710) |
| 16 | 29716650 | BUFFER (#29716650) |
| 17 | 98054318 | BOLT (#98054318) |
| 18 | 61013800 | SPRING WASHER (#61013800) |
| 19 | 19705900 | PLUG (#19705900) |
| 20 | 30464310 | LIFT HANDLE (#30464310) |
| 21 | 30920810 | DECAL A (#30920810) |
| 22 | 92630108 | NUT 8MM (#92630108) |
| 23 | 95004208 | WASHER (#95004208) |
| 24 | 28468700 | SEAT LOCK (#28468700) USE 35782780 |
| 25 | 35782880 | SCREW (#35782880) |
| 26 | 28478550 | STUD (#28478550) |
| 27 | 95000206 | WASHER (#95000206) |
| 28 | 28462333 | #28 U-bolt (#28462333) |
| 29 | 98326010 | SCREW (#98326010) |
| 30 | 98621670 | SCREW (#98621670) |
| 31 | 95021112 | WASHER (#95021112) |
| 32 | 92602312 | NUT (#92602312) |
