1987 1991 GT 1000 Front Fork 1st Series
| Position | Part Number | Description |
|---|---|---|
| 1 | 28494033 | LWR FORK YOKE 63494021 (#28494033) |
| 2 | 18526560 | CAP (#18526560) |
| 3 | 98620560 | SCREW (#98620560) |
| 4 | 95004210 | WASHER (#95004210) |
| 5 | 91181110 | BUSHING (#91181110) |
| 6 | 18513560 | SHIM (#18513560) |
| 7 | 28493133 | #07 Upper plate (#28493133) |
| 8 | 98620540 | SCREW (#98620540) |
| 9 | 18516660 | BUSHING (#18516660) |
| 10 | 18513460 | NUT (#18513460) |
| 11 | 28522533 | RH SLEEVE-CHR. B (#28522533) |
| 12 | 28522633 | LH SLEEVE-CHR. B (#28522633) |
| 13 | 90403449 | FORK SEAL (#90403449) |
| 14 | 96508021 | STUD BOLT (#96508021) |
| 15 | 98622312 | SCREW (#98622312) |
| 16 | 95100116 | WASHER (#95100116) |
| 17 | 63525400 | FORK TUBE (#63525400) |
| 18 | 14524500 | FORK DUST COVERS (#14524500) |
| 19 | 29526400 | FRONT SHOCK (#29526400) |
| 20 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 21 | 14527800 | TUBE (#14527800) |
| 22 | 18526960 | SPRING (#18526960) |
| 23 | 18527960 | SPACER (#18527960) |
| 24 | 18526660 | SPRING (#18526660) |
| 25 | 14527900 | CUP (#14527900) |
| 26 | 90271014 | RING USE 90271015 (#90271014) |
| 27 | 90706238 | O RING (#90706238) |
| 28 | 29527400 | SPACER (#29527400) |
| 29 | 95510308 | DOWEL (#95510308) |
| 30 | 92781100 | CAP NUT CHROME (#92781100) |
| 31 | 92602308 | NUT (#92602308) |
| 32 | 23943410 | CHROME PLUG (#23943410) |
| 33 | 23496110 | RH H/L BRACKET (#23496110) |
| 33 | 28496133 | H/L MOUNT RH (#28496133) |
| 34 | 23496210 | LH H/L BRKT A (#23496210) |
| 35 | 28500233 | PLATE (#28500233) |
| 36 | 23497910 | SPACER (#23497910) |
| 37 | 98622425 | ALLEN BOLT (#98622425) |
| 41 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 42 | 29529600 | AIR PIPE (#29529600) |
| 43 | 28556350 | WASHER SPECIAL PLASTIC WASHER (#28556350) |
| 44 | 28556250 | VALVE (#28556250) |
| 45 | 28556450 | SCREW (#28556450) |
| 47 | 98620590 | SCREW (#98620590) |
