1987 1991 GT 1000 Rear Wh Spokes 1st Series
| Position | Part Number | Description |
|---|---|---|
| 1 | 28630633 | WHEEL 1000 S (#28630633) |
| 2 | 28611733 | NIPPLES (#28611733) |
| 3 | 28631133 | SPOKE-SHORT (#28631133) |
| 4 | 28611633 | SPOKE LONG (#28611633) |
| 5 | 92602316 | AXLE NUT (#92602316) |
| 6 | 14634400 | RING (#14634400) |
| 7 | ||
| 8 | 17633360 | REAR AXLE (#17633360) |
| 9 | 92630508 | NUT (#92630508) |
| 10 | 17633050 | WHEEL HUB COMPL (#17633050) |
| 11 | 98052445 | BOLT (#98052445) |
| 12 | 18635760 | DISC (#18635760) |
| 13 | 98054312 | BOLT (#98054312) |
| 14 | 95021106 | WASHER, WAVE (#95021106) |
| 15 | 17335950 | LOCK PLATE (#17335950) |
| 16 | 14335303 | RING (#14335303) |
| 17 | 14335203 | HUB (#14335203) |
| 18 | 01336800 | RUBBER BLOCK (#01336800) |
| 19 | 28636033 | #19 Spacer (#28636033) |
| 20 | 90272047 | CIRCLIP (#90272047) |
| 21 | 14620301 | FLANGE OR BEARING CARRIER (#14620301) |
| 22 | 92204220 | BEARING (#92204220) |
| 23 | ||
| 24 | 90706490 | O RING (#90706490) |
| 25 | 17633550 | CUP (#17633550) |
| 26 | 12616101 | BALANCE WEIGHT (#12616101) |
| 26 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 26 | 12616103 | BALANCE WEIGHT (#12616103) |
| 27 | 28630733 | WHEEL RIM REAR C (#28630733) |
