1987 1991 GT 1000 Rh Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 28660278 | MASTER CYLINDER (#28660278) |
| 1 | 29660250 | #01 Front master cylinder (#29660250) |
| 2 | 27664075 | HALF CLAMP (#27664075) |
| 2 | 98812216 | #02 Screw (#98812216) |
| 3 | 28657140 | FLEX PIPE (#28657140) |
| 4 | 95990028 | SCREW (#95990028) |
| 5 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 6 | 17658460 | CLAMP (#17658460) |
| 7 | 17658260 | RUBBER RING (#17658260) |
| 8 | 28653001 | CALIPER (#28653001) |
| 9 | 98054525 | BOLT (#98054525) |
| 10 | 95129180 | WAVE WASHER (#95129180) |
| 11 | 14498550 | PLUG (#14498550) |
| 12 | 95100332 | SHIM 0.5 MM (#95100332) |
| 12 | 95100333 | SHIM 0.8 MM (#95100333) |
| 13 | 23661110 | #13 Cover (#23661110) |
| 13 | 27661115 | MASTER CYL LID KIT (#27661115) |
| 14 | 23659310 | #14 Brake mast.cyl rev. kit (#23659310 ) |
| 14 | 28659378 | MASTER CYL KIT (#28659378) |
| 15 | 17654760 | COVER (#17654760) |
| 16 | 28654601 | (#28654601) |
| 17 | 17659260 | BLEEDER SCREW KIT (#17659260) |
| 18 | 14659100 | BRAKE PINS KIT 2 PER BAG (#14659100) |
| 19 | 14659000 | CALIPER KIT (#14659000) |
| 20 | 39663801 | DUST CAP (#39663801) |
| 21 | 27604815 | LEVER PIN (#27604815) |
| 22 | 27663615 | RUBBER USE BREMBO #110.3530.40 (#27663615) |
| 23 | 27749815 | MICROSWITCH (#27749815) |
| 24 | 98200214 | SCREW (98200214) (#98200214) |
| 25 | 28605678 | BRAKE LEVER (28605678) (#28605678) |
| 26 | 92608202 | NUT A (#92608202) |
| 27 | 92295708 | BALL (#92295708) |
| 28 | 93180080 | PLUG (#93180080) |
