1987 1993 California III Carbureted Crankcase
| Position | Part Number | Description |
|---|---|---|
| 1 | 14000765 | CRANKCASE USE 29000750 (#14000765) |
| 2 | 12003900 | PLUG CAP (#12003900) |
| 3 | 96508066 | SHORT STUD (#96508066) |
| 4 | 96508075 | LONG STUD (#96508075) |
| 5 | ||
| 6 | 92781082 | ACORN NUT (#92781082) |
| 7 | 12018900 | BUSH (#12018900) |
| 8 | 95512081 | PIN (#95512081) |
| 9 | 14011900 | Front Main Bearing (#14011900) |
| 9 | 14011901 | Front Main Bearing 1ST U/S (#14011901) |
| 10 | 12012200 | PIN (#12012200) |
| 11 | 98054425 | BOLT (#98054425) |
| 12 | 61270300 | WASHER (#61270300) |
| 13 | 18001150 | COVER SPACER (#18001150) |
| 14 | 98310630 | SCREW (#98310630) |
| 15 | 29001453 | TIMING COVER B (#29001453) |
| 16 | 12001200 | TIMING COVER GASKET (#12001200) USE 05001231 |
| 17 | 90402038 | SEAL RING (#90402038) For Saprisa equipt bikes. |
| 18 | 98612325 | BOLT (#98612325) |
| 19 | 98610335 | BOLT (#98610335) |
| 20 | 18001650 | ALTERNATOR COVER PLASTIC (#18001650) |
| 21 | 14003600 | PAN GASKET (#14003600) |
| 22 | 14003501 | OIL SUMP 03003501 (#14003501) |
| 23 | 14003800 | FILLER CARTRIDG (#14003800) |
| 24 | 28004950 | DIPSTICK (#28004950) |
| 25 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 26 | 98052390 | BOLT (#98052390) |
| 27 | 95004206 | WASHER (#95004206) |
| 29 | 12011800 | REAR MAIN FLANGE BEARING GASKET (#12011800) |
| 30 | 12011400 | Rear Main Bearing (#12011400) |
| 30 | 12011401 | Rear Main Bearing U/S 2MM (#12011401) |
| 30 | 12011402 | Rear Main Bearing (#12011402) |
| 30 | 12011403 | Rear Main Bearing (#12011403) |
| 31 | 12011700 | PIN (#12011700) |
| 32 | 90405367 | CRANKSHAFT SEAL - REAR MAIN (#90405367) |
| 33 | 29999000 | CAL II GSKT.SET (#29999000) |
| 34 | 17999550 | SEAL KIT ENGINE (#17999550) |
| 35 | 98610355 | ALLEN BOLT (#98610355) |
| 36 | 14003240 | FLANGE (#14003240) |
| 37 | 39616800 | PLUG (#39616800) |
| 38 | 92601208 | NUT (#92601208) |
| 39 | 29991051 | #38 Engine w/o gearbox (#29991051) |
