1987 1993 California III Carbureted Electrical System
| Position | Part Number | Description |
|---|---|---|
| 1 | 29747150 | HARNESS (#29747150) |
| 1 | 29747170 | WIRING HARNESS A (#29747170) |
| 1 | 29747171 | WIRING HARNESS A (#29747171) |
| 2 | 12717600 | Cap (#12717600) |
| 3 | 29747250 | #03 Dashboard cable (#29747250) |
| 3 | 29747251 | #03 Dashboard cable (#29747251) |
| 3 | 29747252 | DASH HARNESS A (#29747252) |
| 4 | 29725850 | ALTERNATOR HARNESS (#29725850) |
| 5 | 29726450 | ALT CABLE FOR SAPRISA ALT. (#29726450) |
| 6 | 23707100 | CABLE BOOT (#23707100) |
| 7 | 14748450 | BATTERY GROUND STRAP (#14748450) |
| 8 | 19707100 | CAP (#19707100) |
| 9 | 28747960 | GROUND STRAP (#28747960) |
| 10 | 28732560 | RELAY (#28732560) |
| 10 | 30732510 | RELAY (#30732510) |
| 11 | 29732550 | RELAY (#29732550) |
| 12 | 17750520 | TURN SIGNAL FLASHER (#17750520) |
| 13 | 98202516 | SCREWS (#98202516) |
| 14 | 95004205 | WASHER (#95004205) |
| 15 | 92660501 | CAGE NUT (#92660501) |
| 16 | 30743000 | FUSE BOX ASSY A (#30743000) |
| 17 | 28742560 | FUSE 15A (#28742560) use 290860 |
| 18 | 95100059 | WASHER (#95100059) |
| 19 | 23747310 | T/LAMP HARNESS A (#23747310) |
| 20 | 14609650 | TIE WRAP (#14609650) |
| 21 | 19007700 | RUBBER (#19007700) |
