1987 1993 California III Carbureted Foot Rests
| Position | Part Number | Description |
|---|---|---|
| 1 | 29420350 | FRAME RAIL RH C (#29420350) |
| 2 | 29422150 | FRAME RAIL LH C (#29422150) |
| 3 | 29446950 | RH COVER A (#29446950) |
| 4 | 29447450 | LH COVER (#29447450) |
| 5 | 98230612 | ALLEN SCREW (#98230612) |
| 6 | 92601206 | NUT (#92601206) |
| 7 | 92660601 | CAGE NUT (#92660601) |
| 8 | 18447050 | FLOORBOARD PAD EACH (#18447050) |
| 9 | 29443450 | FLOORBOARD ASSY (#29443450) |
| 10 | 98107035 | BOLT CHROME (#98107035) |
| 11 | 92700073 | NUT (#92700073) |
| 12 | 28429560 | FRONT ENGINE BOLT (#28429560) |
| 13 | 95001213 | WASHER A (#95001213) |
| 14 | 92601312 | NUT A (#92601312) |
| 15 | 29443550 | MOUNT (#29443550) |
| 16 | 23440710 | RF FOOTPEG A (#23440710) |
| 17 | 29446050 | L H PLATE (#29446050) |
| 18 | 23441810 | LF FOOTPEG A (#23441810) |
| 19 | 23443210 | FOOTREST RUBBER (#23443210) |
| 20 | 23441210 | FOOTREST PLATE (#23441210) |
| 21 | 98054314 | SCREW (#98054314) |
| 22 | 95129130 | SHAKE PROOF WASHER (#95129130) |
| 23 | 91180602 | SPACER (#91180602) |
| 24 | 29442250 | BOLT (#29442250) |
| 25 | 61270300 | WASHER (#61270300) |
| 26 | 92781081 | CAP NUT (#92781081) USE STCN8MM |
| 27 | 98623635 | SCREW USE 9881 3635 (#98623635) |
| 28 | 98621650 | SCREW (#98621650) |
| 29 | 17444250 | SPACER (#17444250) |
| 30 | 95100414 | WASHER (#95100414) |
| 31 | 95021112 | WASHER (#95021112) |
| 32 | 92602512 | NUT (#92602512) |
| 33 | 92602312 | NUT (#92602312) |
| 34 | 98074345 | BOLT (#98074345) |
| 35 | 93180245 | RUBBER PLUG (#93180245) |
| 36 | 95001206 | WASHER (#95001206) |
