1987 1993 California III Carbureted Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 29400150 | #01 Frame (#29400150) |
| 2 | 28782550 | LOCK (#28782550) |
| 3 | 29749750 | RH CONN PLATE A (#29749750) |
| 4 | 98054312 | BOLT (#98054312) |
| 5 | 61013800 | SPRING WASHER (#61013800) |
| 6 | 92602206 | NUT (#92602206) USE STHN6MM |
| 7 | 29749850 | LH CONN PLATE A (#29749850) |
| 8 | 29469250 | STUD (#29469250) |
| 9 | 93180080 | PLUG (#93180080) |
| 10 | 92660601 | CAGE NUT (#92660601) |
| 11 | 39103400 | RUBBER PAD FOR GAS TANK (#39103400) |
| 12 | 98054318 | BOLT (#98054318) |
| 13 | 39103500 | PLATE (#39103500) |
| 14 | 91180605 | SPACER (#91180605) |
| 16 | 92601206 | NUT (#92601206) |
| 17 | 29479651 | TOOL TRAY A (#29479651) |
| 18 | 98326009 | SCREW (#98326009) |
| 20 | 19705900 | PLUG (#19705900) |
| 21 | 98326010 | SCREW (#98326010) |
| 22 | 29418250 | BATTERY PLATE A (#29418250) |
| 23 | 29461450 | RUBBER PAD (#29461450) |
| 24 | 98054416 | BOLT (#98054416) |
| 25 | 95004208 | WASHER (#95004208) |
| 26 | 95021108 | WASHER (#95021108) |
| 27 | 92602208 | NUT (#92602208) |
| 28 | 95000208 | WASHER (#95000208) |
| 29 | 30716710 | PLATE A (#30716710) |
| 30 | 29716650 | BUFFER (#29716650) |
