1988 1990 California III Full Fairing 1000 Battery
| Position | Part Number | Description |
|---|---|---|
| 2 | ||
| 3 | ||
| 4 | 98620250 | SCREW (#98620250) |
| 5 | 95021105 | LOCK WASHER (#95021105) |
| 6 | 28712459 | SCREW (SAPRISA) (#28712459) |
| 7 | 14716503 | Coil (#14716503) |
| 8 | ||
| 9 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 10 | ||
| 11 | 30717010 | SPARK PLUG BP6ES (#30717010) |
| 12 | 14730706 | STARTER MOTOR {USE 30730711 VALEO STARTER) (#14730706) |
| 13 | 14730558 | SOLENOID SEE 1473 0558A (#14730558) |
| 14 | 98072480 | BOLT A (#98072480) |
| 15 | 95004208 | WASHER (#95004208) |
| 16 | 92781082 | ACORN NUT (#92781082) |
| 17 | 14730570 | REV.KIT (#14730570) |
| 18 | 19733350 | COVER, SOLENOID NLA 7/15/02 (#19733350) |
| 19 | 28712500 | CONNECTOR (#28712500) |
| 20 | 28704900 | STRAP (#28704900) |
| 21 | 17715450 | DISTRIBUTOR REGULATOR (#17715450) |
| 22 | ||
| 23 | 14716200 | GEAR (#14716200) |
| 24 | 95510318 | PIN (#95510318) |
| 25 | 14716400 | DISTRIBUTOR BASE GASKET (#14716400) |
| 26 | 98052430 | BOLT (#98052430) |
| 27 | 14615901 | WASHER (#14615901) |
| 28 | 14715700 | PLATE (#14715700) |
| 29 | 91180907 | SPACER (#91180907) |
| 31 | 14719800 | POINTS & COND. DISTRIBUTOR KIT (#14719800) |
| 32 | 28703800 | REG (SAPRISA) (#28703800) |
| 33 | 98202516 | SCREWS (#98202516) |
| 34 | 95100059 | WASHER (#95100059) |
| 35 | 95129100 | WASHER (#95129100) |
| 36 | 92660501 | CAGE NUT (#92660501) |
