1988 1990 California III Full Fairing 1000 Front Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 294343602 | FRONT FENDER (#294343602) |
| 2 | 29435750 | UPPER BRACE A (#29435750) |
| 3 | 29435960 | LOWER BRACE A (#29435960) |
| 4 | 98230816 | SCREW (#98230816) |
| 5 | 61270300 | WASHER (#61270300) |
| 6 | 98822314 | SCREW (#98822314) |
| 7 | 95100121 | WASHER (#95100121) |
| 8 | 29436550 | GUIDE (#29436550) |
| 9 | 95021105 | LOCK WASHER (#95021105) |
| 10 | 92602205 | NUT (#92602205) |
| 11 | 294370502 | #11 Rear mudguard, chrome (#294370502) |
| 12 | 91551099 | RUBBER (#91551099) |
| 13 | 28912740 | SHOCK ADJ TOOL (#28912740) |
| 14 | 28929940 | TOOL KIT 14929955 (#28929940) |
| 15 | 29900051 | O MANL CAIII USE 2990 0061 (#29900051) |
| 15 | 29900052 | #15 Operator's handbook (#29900052) |
| 15 | 29900053 | #15 Operator's handbook (#29900053) |
| 15 | 29900060 | #15 Operator's handbook (#29900060) |
