1988 1990 California III Full Fairing 1000 Gear Lever
| Position | Part Number | Description |
|---|---|---|
| 1 | 17250840 | SHIFT LEVER (#17250840) |
| 2 | 18252050 | BUSH NLA (#18252050) USE 30678160 |
| 3 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 4 | 98230816 | SCREW (#98230816) |
| 5 | 61270300 | WASHER (#61270300) |
| 6 | 18259151 | WASHER (#18259151) |
| 7 | 90271008 | SNAP RING (#90271008) |
| 8 | 18257651 | SHIFT ROD (#18257651) |
| 9 | 18257551 | BLOCK (#18257551) |
| 10 | 92690074 | #10 Nut (#92690074) |
| 11 | 18256950 | CONTROL LEVER (#18256950) |
| 12 | 17252050 | BUSH (#17252050) |
| 13 | 98073660 | BOLT (#98073660) |
| 14 | 95100409 | WASHER (#95100409) |
| 15 | 94322185 | SPRING (#94322185) |
| 16 | 92601512 | NUT (#92601512) |
| 17 | 95770265 | PIN (#95770265) |
| 18 | 95129110 | WASHER (#95129110) |
| 19 | 95500222 | SPLIT PIN (#95500222) |
| 20 | 18257801 | SHIFT ROD (#18257801) |
| 21 | 12626800 | FORK (#12626800) |
| 22 | 92601206 | NUT (#92601206) |
| 24 | 18258101 | BALL JOINT (#18258101) use 32258110 |
| 25 | 61013800 | SPRING WASHER (#61013800) |
| 26 | 92630107 | NUT NYLOC (#92630107) |
| 27 | 18258201 | SHIFT SELECTOR ARM (#18258201) |
| 28 | 98072325 | BOLT (#98072325) |
