1989 1994 S 1000 Taillight
| Position | Part Number | Description |
|---|---|---|
| 1 | 23740910 | TAILLIGHT ASSY. (#23740910) |
| 2 | 23741710 | CAIII TAIL LIGHT LENS (#23741710) |
| 3 | 93450224 | BULB T.L. (#93450224) |
| 4 | 14474370 | TAIL LIGHT BRKT A (#14474370) |
| 5 | 92602512 | NUT (#92602512) |
| 6 | 29750662 | RH FRT SIGNAL ROUND (#29750662) |
| 6 | 29750663 | LH FRT SIGNAL ROUND (#29750663) |
| 7 | 29753760 | CAL III T/S LENS ROUND (#29753760) |
| 8 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 9 | 95021112 | WASHER (#95021112) |
| 10 | 28475972 | #10 Rubber protection (#28475972) |
| 11 | 28475872 | #11 Plate holder support (#28475872) |
| 12 | 98054310 | ADJ. BOLT (#98054310) |
| 13 | 95004206 | WASHER (#95004206) |
| 14 | 95129110 | WASHER (#95129110) |
| 15 | 92781062 | NUT (#92781062) |
| 16 | 98230620 | ALLEN BOLT (#98230620) |
| 17 | 92630206 | NUT (#92630206) |
| 18 | 93301175 | CABLE CLAMP (#93301175) |
| 19 | 14468470 | T/S BRACKET A (#14468470) |
| 20 | 98054325 | BOLT (#98054325) |
| 21 | 10475900 | GASKET (#10475900) |
| 22 | 284746001 | #19 Plate holder support (#284746001) |
| 23 | 98200410 | SCREW (#98200410) |
| 24 | 92630104 | NUT (#92630104) |
| 25 | 27475461 | REAR GUARD (#27475461) |
