1990 1993 California III Injected 1000 Drive Shaft
| Position | Part Number | Description |
|---|---|---|
| 1 | 29064161 | #01 Drive shaft (#29064161) |
| 2 | 12065400 | CRANK PLUG (#12065400) |
| 3 | 91702355 | WOODRUFF KEY (#91702355) |
| 4 | 14072001 | SPROCKET (#14072001) |
| 5 | 95028025 | WASHER (#95028025) |
| 6 | 93601026 | CRANK RING NUT (#93601026) |
| 7 | 29067060 | FLYWHEEL FI NLA USE 03067030 (#29067060) |
| 8 | 14615901 | WASHER (#14615901) |
| 9 | 12067701 | SCREW (#12067701) use 597150 |
| 10 | 17067900 | RING GEAR (#17067900) |
| 12 | 98054420 | BOLT (#98054420) |
| 13 | 30061500 | CON ROD ASSY C (#30061500) |
| 14 | 91112128 | BUSH-CON ROD (#91112128) |
| 15 | 92731090 | NUT (#92731090) |
| 16 | 30062260 | CON ROD BOLT (#30062260) |
| 17 | 30062000 | ROD BRG HALF STD (#30062000) USE 01062030 |
| 17 | 30062001 | HALF BEARING 1ST (#30062001) |
| 17 | 30062002 | ROD BRG 2ND (#30062002) |
| 17 | 30062003 | ROD BRG 3RD (#30062003) |
| 18 | 29060400 | PISTON BARE (#29060400) |
| 19 | 14060760 | PISTON RING-TOP A (#14060760) |
| 20 | 18060950 | PISTON RING (#18060950) |
| 21 | 14061060 | OIL RING (#14061060) |
| 22 | 28061260 | WRIST PIN (#28061260) |
| 23 | 27061385 | CIRCLIP (#27061385) |
| 25 | 18060601 | RING SET USE MC 128 (#18060601) |
| 26 | 37045006 | PUSHROD (#37045006) |
| 27 | 10045801 | TAPPET OR PLUNGER (#10045801) |
| 27 | 10045802 | VALVE PLUNGER (#10045802) |
| 27 | 17045860 | TAPPET (#17045860) |
| 28 | 29053351 | CAMSHAFT (#29053351) |
| 29 | 12054000 | FLANGE (#12054000) |
| 30 | 98054320 | BOLT (#98054320) |
| 31 | 95120065 | WASHER (#95120065) |
| 32 | 29054460 | CAM SPROCKET A (#29054460) |
| 34 | 14433400 | WASHER (#14433400) |
| 35 | 92602518 | NUT (#92602518) |
| 36 | 28058060 | TIMING CHAIN (#28058060) USE 05058030 |
| 37 | 30057810 | CHAIN TENSIONER (#30057810) |
| 38 | 61270300 | WASHER (#61270300) |
| 39 | 98052435 | BOLT (#98052435) |
