1990 1993 California III Injected 1000 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 29400180 | FRAME CA3FI C (#29400180) |
| 2 | 29749770 | BRACKET A (#29749770) |
| 3 | 98054312 | BOLT (#98054312) |
| 4 | 61013800 | SPRING WASHER (#61013800) |
| 5 | 28576590 | CLIP A (#28576590) |
| 6 | 29469250 | STUD (#29469250) |
| 7 | 92660601 | CAGE NUT (#92660601) |
| 8 | 29479560 | TOOL TRAY A (#29479560) |
| 9 | 93180080 | PLUG (#93180080) |
| 10 | 29418360 | BATTERY PLATE (#29418360) |
| 11 | 39103400 | RUBBER PAD FOR GAS TANK (#39103400) |
| 12 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 13 | 39103500 | PLATE (#39103500) |
| 14 | 91180605 | SPACER (#91180605) |
| 15 | 92601206 | NUT (#92601206) |
| 16 | 93180706 | PLUG (#93180706) |
| 17 | 98054416 | BOLT (#98054416) |
| 18 | 95004208 | WASHER (#95004208) |
| 19 | 95021108 | WASHER (#95021108) |
| 20 | 92602208 | NUT (#92602208) |
| 21 | 95000208 | WASHER (#95000208) |
| 22 | 19705900 | PLUG (#19705900) |
| 23 | 28782550 | LOCK (#28782550) |
