1991 1993 Nevada 750 Cylinder Head
| Position | Part Number | Description |
|---|---|---|
| 1 | 31022115 | #01 RH head (#31022115) |
| 2 | 31022215 | #02 LH head (#31022215) |
| 3 | 61036801 | GUIDE (#61036801) |
| 4 | 90353009 | RING (#90353009) |
| 5 | 96506042 | STUD (#96506042) |
| 6 | 19025300 | VIBR. DAMPER PI (#19025300) |
| 7 | 19021920 | NUT (#19021920) |
| 8 | 19037820 | VALVE SEAL (#19037820) |
| 9 | 31023500 | #09 Valves cover, stain. (#31023500) |
| 10 | 19023700 | V/C GASKET (#19023700) USE 887002 |
| 11 | 92603010 | NUT A (#92603010) |
| 12 | ||
| 13 | 95129180 | WAVE WASHER (#95129180) |
| 14 | 96510214 | CYLINDER STUD (#96510214) |
| 15 | 96510158 | #15 Tie rod 162 mm (#96510158) |
| 16 | 98620325 | ALLEN BOLT (#98620325) |
| 17 | 31060116 | #17 Cylinder with piston (#31060116) |
| 18 | 19021360 | BUSHING (#19021360) |
| 19 | 27022060 | HD GSKT (#27022060) |
| 20 | 96508145 | CYLINDER STUD (#96508145) |
| 21 | 61270300 | WASHER (#61270300) |
| 22 | 93180245 | RUBBER PLUG (#93180245) |
| 23 | 61027200 | O RING (#61027200) |
| 24 | 27020820 | BASE GASKET A (#27020820) |
| 25 | 90706076 | O RING (#90706076) |
| 26 | 19032980 | SPACER (#19032980) |
